Root NIBPT
CAUTION: Unanticipated failure or alteration of network components (including but not
limited to: disconnection or malfunctioning of a networking device/switch/router/ethernet
cable) may result in loss of connectivity of Kite to other hospital systems. Altering or making
changes to the hospital network should be done with proper knowledge.
Connecting Root to Patient SafetyNet
Root can be configured to connect to Patient SafetyNet wirelessly by authorized and trained
personnel only.
The wireless icon in the Status Bar on Root displays the current connection status. See About
the Main Screen on page 33.
Icon Description
A gray icon indicates Root wireless radio is on, but it is not connected to a wireless
network.
A blue icon indicates Root is connected to a wireless network, but not
communicating with Patient SafetyNet.
A green icon indicates Root is connected to a wireless network and communicating
directly with Patient SafetyNet.
Ethernet
Use the Ethernet screen to enable or disable Ethernet connectivity. When Ethernet
connectivity is enabled, the Ethernet icon will appear in the Status Bar. See About the Status
Bar on page 34.
Option Description
Enables or disables Ethernet
Ethernet
connectivity.
Additional fields in the Ethernet screen display read-only settings about the Ethernet
connectivity that cannot be configured by the user.
www.masimo.com
Factory Default
Setting
On
67
Chapter 3: Operation
Configurable
Settings
On or Off
