Using the Touchscreen Interface

Use the gestures described below to customize the viewing experience, including displaying
the highest priority parameters and measurements. The availability of navigation features is
dependent on the connected medical devices.
Action Illustration Example
Press
Slide
Swipe
Pinch
Drag
and
Drop
Below is a list of all the different types of controls available on Root and the various ways to
interact with each type of control.
Control Applicable Actions
Toggle Slide knob
Press left or right of
toggle
www.masimo.com
See Customizing Windows on
page 46.
Description
Switches between toggle states
Quickly moves knob left or right
Description
Press and release. Action performed
once finger is released.
Press, move (left, right, up or down),
and release. Moves an object across
the display.
Press, move (left, right, up or down),
and release quickly.
Press, move, and release two points.
Moving points apart zooms in, and
moving them together zooms out.
Press, hold, drag an object to
desired position, and drop it by
releasing.
