Initial Battery Charging

To charge the battery for the first time
1. Securely plug the AC power cord into power entry module.
2. Plug the hospital grade AC power cord into an AC power source.
3. Verify that Root's battery is charging by ensuring that the AC Power Indicator (1)
is green and the Battery icon on the Status Bar (2) is solid green or has the
charging symbol. See AC Power Indicator on page 86 and About the Status Bar
on page 34.
4. The Root Charging Indicator remains orange while the battery is charging and
will illuminate green when Root is fully charged. See Root Battery on page 68
and About the Status Bar on page 34.
See Safety Information, Warnings, and Cautions on page 13.
