Root NIBPT
Radical-7 and Radius-7 Battery
Use the Battery screen to view the specific percentage of charge on the Radical-7 or
Radius-7's battery. For Radical-7, the user can also access the Battery screen by pressing the
Battery icon on the Status Bar. See About the Status Bar on page 34.
Option
State of Charge
Battery Diagnostics Allows trained personnel to access battery diagnostic information.
Brightness
Use the Brightness screen to adjust the brightness of the Root display.
Option Description
Auto Allows automatic adjustment of Root's
display brightness based on ambient light. Off
Brightness
Adjust the brightness level of the Root
Brightness display by sliding the button (4 is
brightest).
www.masimo.com
Description
Provides a read-only display of battery level remaining.
Factory
Default
Setting
4
69
Chapter 3: Operation
Configurable
Settings
On or Off
1, 2, 3, 4
