Root NIBPT

Alarms

Audio Alarm System Status
Type Light Color
High Priority Flashing Red
Medium Flashing Yellow
Priority
Low Priority Solid Yellow

Nurse Call Specifications

The Nurse Call relays have the following electrical specifications per switch:
Parameter Specification
Max Voltage 36 VDC or 24 VAC peak

Connectors

Connector Type
Ethernet 10/100 Mbps
Nurse Call 1/4 inch round female
MOC-9 Masimo Connector
USB USB 2.0
Iris RS-232/RJ-45
NIBP Nib Male Bayonet
Temperature MOLEX 52271-0690
www.masimo.com
Audio Description
10-pulse burst, pulse spacing: 0.250s, 0.250s,
0.500s, 0.250s, repeat time:10s
3-pulse burst, pulse spacing: 0.375s, 0.375s, repeat
time: 7s
No audio
Number of Ports
1
1
3
2
4
1
1
134
Chapter 15: Specifications
