Root NIBPT
Ref. Feature Description
The area where all data from a docked Radical-7, Radius-7, or connected
1 Window
MOC-9 module are displayed.
This menu allows the user to change between Trend View and Analog
Action View. For NIBP and Temperature, the action menu allows access to
2
Menu additional settings. Sensitivity settings can also be selected through the
action menu.
Waveform Shows a parameter or measurement over time (only for Radical-7,
3
Radius-7, and MOC-9 modules).
(Available only in Trend View) Parameters and measurements are shown
Trend as Trend Displays in Trend View. A parameter or measurement's Trend
4a
Display Display includes its Value Range, Numeric Value, Alarm Limits and
Parameter label. See Using Trend View on page 43.
(Available only in Analog View) Parameters and measurements are shown
Analog as Analog Gauges in Analog View. A parameter's Analog Gauge includes its
4b
Gauge Alarm Limits, Numeric Value, Parameter Label, as well as Alarming,
Caution and Normal Ranges. See Using Analog View on page 44.
Displays parameters and measurements which are not shown as Trend
5 Well
Displays or Analog Gauges.
