Chapter 7: Electronic Medical Record (Emr) Push; Determining Emr Push Is Active; Manually Entering Patient Data - Masimo Root Operator's Manual

Chapter 7: Electronic Medical Record
(EMR) Push
The Electronic Medical Record (EMR) Push feature allows clinicians to send validated patient
vitals data from any of the Masimo devices, MOC-9 modules, or Iris devices connected to Root
directly to a Patient Data Management System, such as an Electronic Medical Record (EMR).

Determining EMR Push is Active

The EMR Push icon
feature is active. The EMR Push feature is active when a Root patient profile is connected to a
Patient SafetyNet server. If the EMR Push icon does not appear, see Masimo Technical
Services on page 160.
Note: The Patient SafetyNet server can be configured to require clinicians to provide access
credentials to activate the EMR Push feature. To configure Patient SafetyNet to require access
credentials, see Masimo Technical Services on page 160.

Manually Entering Patient Data

Follow the instructions below to manually enter patient data.
Note: Parameters with manual entry permissions can be pre-configured on Patient
SafetyNet. See Masimo Technical Services on page 160.
1. In the EMR Push screen, press a parameter that has a pencil icon
2. In the manual entry screen, move the slide knob or press the spinner to select the
desired parameter value.
Press OK to accept the selected manual entry value, or press Cancel to delete the
3.
manual entry value and return to the EMR Push screen. After pressing OK, the
selected manual entry value appears on the EMR Push screen.
www.masimo.com
appears at the bottom of the Root main screen when the EMR Push
109
.
