About The Action Bar - Masimo Root Operator's Manual

Root NIBPT
Ref. Feature
13
Current Time
14
Profiles

About the Action Bar

At the bottom of the Main Screen is the Action Bar with interactive icons. Each icon provides
a shortcut to a menu item or an action on Root.
Ref. Feature
Patient
1
Admit/Discharge*
2
EMR Push*
Session
3
Management
4
Manual Events
5
Main Menu
*These icons will only appear when Root is connected to a Patient SafetyNet system v5.0.0.0
or higher or an Iris Gateway system.
www.masimo.com
Description
Displays the current time and provides access to the Localization
screen which contains settings related to local time, language and
geography.
See Localization on page 65.
Provides access to the Profiles screen. The example shown illustrates
that Profiles is currently set to Adult for an adult patient.
See Profiles on page 75.
Description
Provides access to admit or discharge a patient. See Admit and
Discharge to Patient SafetyNet. on page 103
Provides access to send measured or manually entered patient
parameter data. See Electronic Medical Record (EMR) Push on
page 109.
Provides access to Session Management. See Session
Management on page 82.
Provides access for manual event markers.
Provides access to device control options for Root and
connected medical devices. See Accessing Main Menu Options
on page 49.
36
Chapter 3: Operation
Masimo
