Chapter 13: Messages

The following messages are specific to Root:
Message
Battery Charge is
Low.
MOC-9 module
Disconnected
(e.g. SedLine
Disconnected)
Radical-7
Disconnected
Radius-7
Disconnected
Check Probe
Retake
Measurement
Check Ambient
Temperature
Replace Probe
www.masimo.com
Explanation
The internal battery needs to be
charged. System Status Lights
flash yellow.
A MOC-9 module is disconnected
from Root.
Radical-7 is disconnected from
Root.
Radius-7 is disconnected from
Root.
Probe is not responsive.
An error has occurred in the
process of taking a patient
temperature measurement
with the optional integrated
temperature module.
Ambient temperature may be
too high or too low.
Probe is not responsive due to
not being calibrated or
damaged.
Next Step
Charge Root's battery using AC power.
Reconnect module or acknowledge
message by pressing the Alarm
Silence icon.
Reconnect Radical-7 or acknowledge
message by pressing the Alarm
Silence icon.
Reconnect Radius-7 or acknowledge
message by pressing the Alarm
Silence icon.
Check probe tip condition. Re-insert
probe into probe well or check for
alignment problem. If problem
persists, replace the probe. If problem
still persists, contact Customer
Service.
Try another measurement cycle. If
problem persists, replace probe.
Verify ambient temperature does not
exceed operating specification.
Check internal temperature at probe
well.
Replace probe.
