How to Order

4 How to Order

4.1 Ordering Form

4.1.1 Drive Configurator
It is possible to design an adjustable frequency drive
according to the application requirements by using the
ordering number system.
Order the adjustable frequency drive as either standard or
with integral options by sending a type code string
describing the product a to the local Danfoss sales office,
i.e.:
FC-102P18KT4E21H1XGCXXXSXXXXAGBKCXXXXDX
The meaning of the characters in the string can be located
in the pages containing the ordering numbers in chapter 3
Selection. In the example above, a Profibus LON works
option and a general purpose I/O option is included in the
adjustable frequency drive.
Ordering numbers for adjustable frequency drive standard
variants can also be located in chapter 4 How to Order.
Configure the right adjustable frequency drive for the right
application and generate the type code string in the
Internet-based Drive Configurator. The Drive Configurator
automatically generates an 8-digit sales number to be
delivered to the local sales office.
Furthermore, establish a project list with several products
and send it to a Danfoss sales representative.
The Drive Configurator can be found on the global
Internet site: www.danfoss.com/drives.
MG11BC22
Design Guide
Example of Drive Configurator interface set-up:
The numbers shown in the boxes refer to the letter/figure
number of the type code string; read from left to right.
Product groups
Adjustable frequency drive series
Power rating
Phases
AC Line Voltage
Enclosure
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter
Brake
Display (LCP)
Coating PCB
Line power option
Adaptation A
Adaptation B
Software release
Software language
A options
B options
C0 options, MCO
C1 options
C option software
D options
Table 4.1 Example of Drive Configurator Interface Set-up
