How to Order a Drive

10 How to Order a Drive

10.1 Drive Configurator

1
F C
Table 10.1 Type Code String
Product group
Model
Mains Voltage
Enclosure
Hardware configuration 16–23
RFI filter
Brake
Display (LCP)
PCB coating
10 10
Mains option
Adaptation A
Adaptation B
Software release
Software language
A options
B options
Table 10.2 Type Code Example for Ordering a Drive
72
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
- 3 6 1 T
1–6
7–10
11–12
13–15
16–17
18
19
20
21
22
23
24–27
28
29–30
31–32
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
21
4 E 2 0 H 2 X X C
Configure the correct drive for the proper application by
using the internet-based drive configurator. The drive
configurator is found on the global internet site:
www.danfoss.com/drives. The configurator creates a type
code string and an 8-digit sales number, which can be
delivered to the local sales office. It is also possible to
build a project list with several products and send it to a
Danfoss sales representative.
An example of a type code string is:
FC-361N132T4E20H2XXCXXXSXXXXA0BX
The meaning of the characters in the string is defined in
this chapter. In the example above, a drive is configured
with the following options:
•
•
•
Drives are delivered automatically with English and
Chinese languages.
22 23 24 25 26 27 28 29 30
X X X S X X X X A
RFI filter, Class A2.
3C3.
PROFIBUS DP-V1.
31 32
B X
