Danfoss VLT FC 102 Series Design Manual page 185

General Specifications and ...
Cable length AC linevoltage
(ft [m]) [V]
120 [36] 240
450 [136] 240
500 [150] 240
Table 9.14 Adjustable frequency drive, P11K, T2
Cable length AC linevoltage
(ft [m]) [V]
100 [30] 240
330 [100] 240
500 [150] 240
Table 9.15 Adjustable frequency drive, P15K, T2
Cable length AC linevoltage
(ft [m]) [V]
120 [36] 240
450 [136] 240
500 [150] 240
Table 9.16 Adjustable frequency drive, P18K, T2
Cable length AC linevoltage
(ft [m]) [V]
120 [36] 240
450 [136] 240
500 [150] 240
Table 9.17 Adjustable frequency drive, P22K, T2
Cable length AC linevoltage
(ft [m]) [V]
50 [15] 240
164 [50] 240
500 [150] 240
Table 9.18 Adjustable frequency drive, P30K, T2
Cable length AC linevoltage
(ft [m]) [V]
100 [30] 240
330 [100] 240
500 [150] 240
Table 9.19 Adjustable frequency drive, P37K, T2
Cable length AC linevoltage
(ft [m]) [V]
100 [30] 240
330 [100] 240
500 [150] 240
Table 9.20 Adjustable frequency drive, P45K, T2
MG11BC22
Design Guide
Rise time
Vpeak
[μsec] [kV]
0.264 0.624
0.536 0.596
0.568 0.568
Rise time
Vpeak
[μsec] [kV]
0.556 0.650
0.592 0.594
0.708 0.575
Rise time Vpeak
[μsec]
[kV]
0.244 0.608
0.568 0.580
0.720 0.574
Rise time Vpeak
[μsec] [kV]
0.244 0.608
0.560 0.580
0.720 0.574
Rise time
Vpeak
[μsec] [kV]
0.194 0.626
0.252 0.574
0.444 0.538
Rise time Vpeak
[μsec] [kV]
0.300 0.598
0.536 0.566
0.776 0.546
Rise time
Vpeak
[μsec] [kV]
0.300 0.598
0.536 0.566
0.776 0.546
Danfoss A/S © Rev. 06/2014 All rights reserved.
dU/dt
[kV/μsec]
1.894
0.896
0.806
dU/dt
[kV/μsec]
0.935
0.807
0.669
dU/dt
[kV/μsec]
1.993
0.832
0.661
dU/dt
[kV/μsec]
1.993
0.832
0.661
dU/dt
[kV/μsec]
2.581
1.929
0.977
dU/dt
[kV/μsec]
1.593
0.843
0.559
dU/dt
[kV/μsec]
1.593
0.843
0.559
183
9 9
