ALARM 30, Motor phase U missing
Motor phase U between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase U.
ALARM 31, Motor phase V missing
Motor phase V between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase V.
ALARM 32, Motor phase W missing
Motor phase W between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase W.
ALARM 33, Soft-charge fault
Too many power-ups have occurred within a short time
period. Let the unit cool to operating temperature.
WARNING/ALARM 34, Serial communication bus
communication fault
9
9
The serial communication bus on the communication
option card is not working.
WARNING/ALARM 36, Line failure
This warning/alarm is only active if the supply voltage to
the frequency converter is lost and 14-10 Mains Failure is
NOT set to [0] No Function. Check the fuses to the
frequency converter and mains supply to the unit.
ALARM 38, Internal fault
When an internal fault occurs, a code number defined in
Table 9.44 is displayed.
Troubleshooting
Cycle power
Check that the option is properly installed
Check for loose or missing wiring
It may be necessary to contact your Danfoss supplier or
service department. Note the code number for further
troubleshooting directions.
No.
0
256-258
512-519
783
1024-1284
1299
202
Text
Serial port cannot be initialized. Contact your
Danfoss supplier or Danfoss Service Department
Power EEPROM data is defective or too old.
Replace power card
Internal fault. Contact your Danfoss supplier or
Danfoss Service Department
Parameter value outside of min/max limits
Internal fault. Contact your Danfoss supplier or the
Danfoss Service Department.
Option SW in slot A is too old
Danfoss A/S © Rev. 06/2014 All rights reserved.
Design Guide
No.
1300
1302
1315
1316
1318
1379-2819
1792
1793
1794
1795
1796
2561
2820
2821
2822
3072-5122
5123
5124
5125
5126
5376-6231
Table 9.44 Internal Fault Codes
ALARM 39, Heatsink sensor
No feedback from the heatsink temperature sensor.
The signal from the IGBT thermal sensor is not available on
the power card. The problem could be on the power card,
on the gate drive card, or the ribbon cable between the
power card and gate drive card.
WARNING 40, Overload of digital output terminal 27
Check the load connected to terminal 27 or remove short-
circuit connection. Check 5-00 Digital I/O Mode and
5-01 Terminal 27 Mode.
WARNING 41, Overload of digital output terminal 29
Check the load connected to terminal 29 or remove short-
circuit connection. Check 5-00 Digital I/O Mode and
5-02 Terminal 29 Mode.
Text
Option SW in slot B is too old
Option SW in slot C1 is too old
Option SW in slot A is not supported (not allowed)
Option SW in slot B is not supported (not allowed)
Option SW in slot C1 is not supported (not
allowed)
Internal fault. Contact your Danfoss supplier or
Danfoss Service Department
HW reset of DSP
Motor-derived parameters not transferred correctly
to DSP
Power data not transferred correctly at power-up
to DSP
The DSP has received too many unknown SPI
messages
RAM copy error
Replace control card
LCP stack overflow
Serial port overflow
USB port overflow
Parameter value is outside its limits
Option in slot A: Hardware incompatible with
control board hardware
Option in slot B: Hardware incompatible with
control board hardware
Option in slot C0: Hardware incompatible with
control board hardware
Option in slot C1: Hardware incompatible with
control board hardware
Internal fault. Contact your Danfoss supplier or
Danfoss Service Department
MG11BC22
