Electrical Installation
Figure 6.3 Tightening the Ground Cable
Figure 6.4 Mounting Line Power Plug and Tightening
Wires
Figure 6.5 Tighten Support Bracket
MG11BC22
Design Guide
AC line input connector enclosure type A4/A5 (IP55/66)
Figure 6.6 Connecting to Line Power and Grounding without
Disconnector
Figure 6.7 Connecting to Line Power and Grounding with
Disconnector
When disconnector is used (enclosure type A4/A5), the PE
must be mounted on the left side of the adjustable
frequency drive.
Figure 6.8 AC Line Input Connection Enclosure Types B1 and
B2 (IP21/NEMA Type 1 and IP55/66/ NEMA Type 12)
