How to Order
4.2.2 Ordering Numbers: Harmonic Filters
Harmonic filters are used to reduce line harmonics.
•
AHF 010: 10% current distortion
•
AHF 005: 5% current distortion
4 4
I [A]
AHF, N
10
19
26
35
43
72
101
144
180
217
289
324
370
506
578
648
694
740
Table 4.6 380–415 V AC, 50 Hz
78
Design Guide
Typical Motor Used [kW]
1.1–4
5.5–7.5
11
15–18.5
22
30–37
45–55
75
90
110
132
160
200
250
315
355
400
450
Danfoss A/S © Rev. 06/2014 All rights reserved.
Danfoss Ordering Number
AHF 005 AHF 010
175G6600 175G6622
175G6601 175G6623
175G6602 175G6624
175G6603 175G6625
175G6604 175G6626
175G6605 175G6627
175G6606 175G6628
175G6607 175G6629
175G6608 175G6630
175G6609 175G6631
175G6610 175G6632
175G6611 175G6633
175G6688 175G6691
175G6609 175G6631
+ 175G6610 + 175G6632
2x 175G6610 2x 175G6632
2x175G6611 2x175G6633
175G6611 175G6633
+ 175G6688 + 175G6691
2x175G6688 2x175G6691
Adjustable frequency
drive size
P1K1, P4K0
P5K5–P7K5
P11K
P15K–P18K
P22K
P30K–P37K
P45K–P55K
P75K
P90K
P110
P132–P160
P200
P250
P315
P355
P400
P450
MG11BC22
