Danfoss VLT FC 102 Series Design Manual page 187

General Specifications and ...
Cable length AC linevoltage
(ft [m]) [V]
120 [36] 400
330 [100] 400
500 [150] 400
Table 9.27 Adjustable frequency drive, P22K, T4
Cable length AC linevoltage
(ft [m]) [V]
50 [15] 400
330 [100] 400
500 [150] 400
Table 9.28 Adjustable frequency drive, P30K, T4
Cable length AC linevoltage
(ft [m]) [V]
16.4 [5] 480
164 [50] 480
330 [100] 480
500 [150] 480
Table 9.29 Adjustable frequency drive, P37K, T4
Cable length AC linevoltage
(ft [m]) [V]
120 [36] 400
164 [50] 400
330 [100] 400
500 [150] 400
Table 9.30 Adjustable frequency drive, P45K, T4
Cable length AC linevoltage
(ft [m]) [V]
33 [10] 400
Table 9.31 Adjustable frequency drive, P55K, T4
Cable length AC linevoltage
(ft [m]) [V]
16.4 [5] 480
Table 9.32 Adjustable frequency drive, P75K, T4
Cable length AC linevoltage
(ft [m]) [V]
16.4 [5] 400
Table 9.33 Adjustable frequency drive, P90K, T4
MG11BC22
Design Guide
Rise time
Vpeak
[μsec] [kV]
0.232 0.950
0.410 0.980
0.430 0.970
Rise time
Vpeak
[μsec] [kV]
0.271 1.000
0.440 1.000
0.520 0.990
Rise time Vpeak
[μsec]
[kV]
0.270 1.276
0.435 1.184
0.840 1.188
0.940 1.212
Rise time
Vpeak
[μsec] [kV]
0.254 1.056
0.465 1.048
0.815 1.032
0.890 1.016
Rise time
Vpeak
[μsec] [kV]
0.350 0.932
Rise time Vpeak
[μsec]
[kV]
0.371 1.170
Rise time
Vpeak
[μsec] [kV]
0.364 1.030
Danfoss A/S © Rev. 06/2014 All rights reserved.
dU/dt
[kV/μsec]
3.534
1.927
1.860
dU/dt
[kV/μsec]
3.100
1.818
1.510
dU/dt
[kV/μsec]
3.781
2.177
1.131
1.031
dU/dt
[kV/μsec]
3.326
1.803
1.013
0.913
dU/dt
[kV/μsec]
2.130
dU/dt
[kV/μsec]
2.466
dU/dt
[kV/μsec]
2.264
185
9 9
