Electrical Installation
Step 3. Activate the Automatic Motor Adaptation (AMA)
Performing an AMA ensures optimum performance. The
AMA measures the values from the motor model
equivalent diagram.
1. Connect terminal 37 to terminal 12 (if terminal 37
is available).
2. Connect terminal 27 to terminal 12 or set
5-12 Terminal 27 Digital Input to [0] No function.
3. Activate the AMA 1-29 Automatic Motor
Adaptation (AMA).
4. Select between complete or reduced AMA. If a
sine-wave filter is mounted, run only the reduced
6 6
AMA, or remove the sine-wave filter during the
AMA procedure.
5. Press [OK]. The display shows Press [Hand on] to
start.
6. Press [Hand On]. A progress bar indicates if the
AMA is in progress.
Stop the AMA during operation
1. Press [Off] - the adjustable frequency drive enters
alarm mode and the display shows that the AMA
was terminated by the user.
Successful AMA
1. The display shows Press [OK] to finish AMA.
2. Press [OK] to exit the AMA state.
Unsuccessful AMA
1. The adjustable frequency drive enters alarm
mode. A description of the alarm can be found in
the Warnings and Alarms chapter in the product-
related Instruction Manual.
2. Report Value in the [Alarm Log] shows the last
measuring sequence carried out by the AMA
before the adjustable frequency drive entered
alarm mode. This number along with the
description of the alarm assist in troubleshooting.
If contacting Danfoss for service, make sure to
mention number and alarm description.
NOTICE!
Unsuccessful AMA is often caused by incorrectly
registered motor nameplate data or a difference that is
too large between the motor power size and the
adjustable frequency drive power size.
134
Design Guide
Step 4. Set speed limit and ramp times
Set up the desired limits for speed and ramp time:
Danfoss A/S © Rev. 06/2014 All rights reserved.
3-02 Minimum Reference.
3-03 Maximum Reference.
4-11 Motor Speed Low Limit [RPM] or 4-12 Motor
Speed Low Limit [Hz].
4-13 Motor Speed High Limit [RPM] or 4-14 Motor
Speed High Limit [Hz].
3-41 Ramp 1 Ramp-up Time.
3-42 Ramp 1 Ramp-down Time.
