Table Of Contents - Danfoss VLT FC 102 Series Design Manual

Contents
Contents
1 How to Read this Design Guide
2 Introduction to VLT
2.1 Safety
2.2 CE Labeling
2.3 Air humidity
2.4 Aggressive Environments
2.5 Vibration and Shock
2.6 Safe Torque Off
2.7 Advantages
2.8 Control Structures
2.9 General Aspects of EMC
2.10 Galvanic Isolation (PELV)
2.11 Ground Leakage Current
2.12 Brake Function
2.13 Extreme Running Conditions
3 Selection
3.1 Options and Accessories
MG11BC22
Design Guide
®
HVAC Drive
3.1.1 Mounting Option Modules in Slot B
3.1.2 General Purpose I/O Module MCB 101
3.1.3 Digital Inputs - Terminal X30/1-4
3.1.4 Analog Voltage Inputs - Terminal X30/10-12
3.1.5 Digital Outputs - Terminal X30/5-7
3.1.6 Analog Outputs - Terminal X30/5+8
3.1.7 Relay Option MCB 105
3.1.8 24 V Backup Option MCB 107 (Option D)
3.1.9 Analog I/O option MCB 109
3.1.10 PTC Thermistor Card MCB 112
3.1.11 Sensor Input Option MCB 114
3.1.11.1 Ordering Code Numbers and Parts Delivered
3.1.11.2 Electrical and Mechanical Specifications
3.1.11.3 Electrical Wiring
3.1.12 Remote Mounting Kit for LCP
3.1.13 IP21/IP41/ TYPE1 Enclosure Kit
3.1.14 IP21/Type 1 Enclosure Kit
3.1.15 Output Filters
