How to Order

4 How to Order

4.1 Configuration

4.1.1 Type Code String
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
C D S 8 0 3 P
Illustration 4.1 Type Code
Description
Product group & FC series
Power rating
Number of phases
Mains voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
Mains option
Adaption
Adaption
Software release
Software language
A options
B options
C0 options MCO
C1 options
C option software
D options
Table 4.1 Type Code Descriptions
MG18N202
Design Guide
T H X
Position
1–6
7–10
11
11–12
13–15
16–17
18
19
20
21
22
23
24–27
28
29–30
31–32
33–34
35
36–37
38–39
Danfoss A/S © 12/2015 All rights reserved.
21 22 23 24 25 26 27 28 29 30
X X X S X X X X A X
Possible option
CDS 803
6.0–10 kW (P6K0–P10K)
Three phases (T)
T2: 200–240 V AC
T4: 380–480 V AC
E20: IP20/Chassis
H4: RFI filter class A1
X: No brake chopper included
A: Alpha numeric local control panel
X: No local control panel
X: No coated PCB
C: Coated PCB
X: No mains option
X: No adaption
X: No adaption
SXXXX: Latest release - std. software
X: Standard
AX: No A options
BX: No B options
CX: No C options
X: No C1 options
XX: No options
DX: No D0 options
31 32 33 34 35 36 37 38 39
B X C X X X X D X
