Selection
3.1.11.3 Electrical Wiring
MCB 114
Sensor Input
SW. ver. xx.xx
VDD
I IN
GND TEMP
WIRE
GND TEMP
1
1
X48/
1
2
3
4
5
6
4-20mA
2 or 3
2 or 3
wire
wire
Figure 3.15 Electrical Wiring
Terminal
Name
1
VDD
2
I in
3
GND
4, 7, 10
Temp 1, 2, 3
5, 8, 11
Wire 1, 2, 3
6, 9, 12
GND
Table 3.10 Terminals
MG11BC22
Design Guide
Option B
Code No. 130B1272
WIRE
GND TEMP
WIRE
GND
2
2
3
3
7
8
9 10 11 12
2 or 3
2 or 3
wire
wire
Function
24 V DC to supply 4–20 mA
sensor
4–20 mA input
Analog input GND
Temperature input
Third wire input if three
wire sensors are used
Temp. input GND
Danfoss A/S © Rev. 06/2014 All rights reserved.
3.1.12 Remote Mounting Kit for LCP
The LCP can be moved to the front of a cabinet by using
the remote built-in kit. The enclosure is the IP66. The
fastening screws must be tightened with a torque of max.
1 Nm.
Enclosure
Max. cable length between and unit
Communication std
Table 3.11 Technical Data
Figure 3.16 LCP Kit with Graphical LCP, Fasteners, 10 ft [3 m]
Cable and Gasket
Ordering No. 130B1113
Figure 3.17 LCP Kit with Numerical LCP, Fasteners and Gasket
Ordering no. 130B1114
3
IP66 front
10 ft [3 m]
RS-485
69
3
