Electrical Installation
Figure 6.28 B1 - IP55
Hole number
and
recommended
6 6
use
1) Line power
2) Motor
3) Brake/Load
Sharing
4) Control
Cable
5) Control
Cable
5) Control
2)
Cable
Table 6.10 Legend to Figure 6.28
± 0.007 in [0.2 mm]
1) Tolerance
2) Knockout hole
Figure 6.29 B1 - IP55 Threaded Connector Holes
Hole number and recommended use
1) Line power
2) Motor
3) Brake/Load Sharing
4) Control Cable
5) Control Cable
6) Control Cable
Table 6.11 Legend to Figure 6.29
1) Knockout hole
102
Design Guide
Dimensions 1)
Nearest metric
UL [in] [mm]
1 34.7
1 34.7
1 34.7
3/4 28.4
1/2 22.5
1/2 22.5
Nearest metric
M32
M32
M32
M25
M25
0.89 in [22.5 mm]
