Reference Number Index - ABB REACT-3.6-TL Product Manual

R
eference number index
wall bracket
01
heat sink
02
REACT-UNO
03
display
04
keypad
05
LED panel
06
cable conduit (female)
07
DC disconnect switch
08
cover for area of inverter unit connections
09
plastic cover for inverter unit
10
plastic cover for battery unit
11
cover for area of battery unit connections
12
battery pack
13
REACT-BATT-AP1
14
VSN300 Wi-Fi Logger Card
15
expansion board connector
16
RJ45 connectors for serial RS485 PC
17
termination switch for PC RS485 line
18
termination switch for METER RS485 line
19
termination switch for M-B RS485 line
20
communication and control signal terminal block
21
multifunctional relay terminal block
22
Load Manager Box
23
AC output (back-up) terminal block
24
AC output terminal block
25
SD card holder
26
DC connectors (MPPT2)
27
DC connectors (MPPT1)
28
input mode selection switch
29
battery housing
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
- 9 -
Скачано с сайта интернет магазина https://axiomplus.com.ua/
1 - Introduction and general information
battery communication and control cable
battery power cable
battery protection fuse
smoke sensor (inverter)
ground connection points
cable conduit (male)
power connector (cable from unit on the left)
power connector (cable from unit on the right)
connector for communication and control (cable
from unit on the right)
smoke sensor (battery)
connector for communication and control (cable
from unit on the left)
Rotary switch (RS485 internal line address)
connector for internal communication line (cable
from unit on the right)
termination switch for internal communication line
connector for internal communication line (cable
from unit on the left)
input connectors (MPPT1)
input connectors (MPPT2)
AC cable gland
AC cable gland (back-up)
emergency button
service cable glands
-Wi-Fi antenna support
Wi-Fi antenna
REACT-MTR-1PH
hole for line cable
AC power supply terminal block
METER RS485 serial terminal block
REACT-MTR-3PH
terminal block for three-phase connection
METER RS485 serial terminal block
