F
ield of use, general conditions
You may not use the equipment for a use that does not conform to that provided for in the
field of use. The equipment MUST NOT be used by inexperienced staff, or even experienced
staff if carrying out operations on the equipment that fail to comply with the indications in this
manual and enclosed documentation.
I
ntended or allowed use
L
imits in field of use
The REACT system can be used only with photovoltaic modules which do not require the
grounding of one of the input poles, unless accessories are installed which are compatible
with the inverter and enable this operation to be carried out. In this case you must install an
isolation transformer on the AC side of the system.
Only a photovoltaic generator consisting of class II modules (in accordance with IEC 61730)
can be connected as input to the REACT system (do not connect batteries or other power
sources)
The REACT system can be connected to the electricity grid only in countries for which it has
been certified/approved.
The REACT system cannot be connected on the DC side in parallel to other inverters to
convert energy from a photovoltaic generator with a power greater than the nominal power
of the single inverter.
The REACT system can be used only if all the technical characteristics are observed.
Batteries other than those approved by ABB cannot be connected to the REACT system
ABB accepts no liability for damage of any kind that may arise from
incorrect or careless operations.
The system is designed to optimise self-consumption in residential
contexts and consists of
• REACT-UNO (inverter) transforms a direct current (DC) from a
photovoltaic generator (FV) into an alternating current (AC) which can
be fed into the public distribution grid.
• REACT-BATT (battery pack) temporarily stores unused energy from
the photovoltaic generator which will subsequently be used when the
energy demand from users is greater than the energy produced by the
PV generator
• REACT-MTR (energy meter) which measures energy at the
connection point to the grid and communicates with REACT-UNO in
order to maximise energy self-sufficiency by managing the storage
system.
