• Once the phase of mechanical installation of the METER is finished, it
is necessary to configure the METER in order to make it compatible with
the REACT system. Set the parameters of the meter as set out in the
table:
Parameter
Address
Protocol
Baud rate
Parity
The settings are made by using the keypad and the display on the meter:
1. Press for two seconds
2. Press repeatedly
to confirm.
- Press
3. Press repeatedly
to confirm.
- Press
4. Press repeatedly
- Press to access.
- Press to enable the change in the value.
- Press repeatedly
to confirm the change.
- Press
- Press for two seconds
5. Press repeatedly
- Press to access.
- Press to enable the change in the value.
- Press repeatedly
to confirm the change.
- Press
- Press for two seconds
6. Press repeatedly
- Press to access.
- Press to enable the change in the value.
- Press repeatedly
to confirm the change.
- Press
- Press for two seconds
7. Press repeatedly
- Press to access.
- Press to enable the change in the value.
- Press repeatedly
to confirm the change.
- Press
- 73 -
Скачано с сайта интернет магазина https://axiomplus.com.ua/
to access the setup menu of the meter.
until the display shows "Set".
until the display shows "RS-485".
until the display shows "Protocol".
until the display shows "Modbus".
to return to the RS485 menu.
until the display shows "Baud rate".
and select 57600.
to return to the RS485 menu.
until the display shows "Address".
and select 1.
to return to the RS485 menu.
until the display shows "Modbus".
and select even.
5 - Installation
Settings
1
MODBUS
57600
EVEN
