Fieldbus - Danfoss Vacon NXP Applications Manual

Parameter list
4.10

Fieldbus

Code Parameter
FB Actual Value
P2.10.1
Sel
P2.10.2 FB Data Out1 Sel
P2.10.3 FB Data Out2 Sel
P2.10.4 FB Data Out3 Sel
P2.10.5 FB Data Out4 Sel
P2.10.6 FB Data Out5 Sel
P2.10.7 FB Data Out6 Sel
P2.10.8 FB Data Out7 Sel
P2.10.9 FB Data Out8 Sel
P2.10.10 FB Data In 1 Sel
P2.10.11 FB Data In 2 Sel
P2.10.12 FB Data In 3 Sel
P2.10.13 FB Data In 4 Sel
P2.10.14 FB Data In 5 Sel
P2.10.15 FB Data In 6 Sel
P2.10.16 FB Data In 7 Sel
P2.10.17 FB Data In 8 Sel
P2.10.18 GSW Data
P2.10.19 State Machine
P2.10.20 FB Ref Min
P2.10.21 FB Ref Max
Control Slot
P2.10.22
Selector
P2.10.23 SW B11 ID.Bit
P2.10.24 SW B12 ID.Bit
P2.10.25 SW B13 ID.Bit
P2.10.26 SW B14 ID.Bit
P2.10.27 uCW B12
P2.10.28 uCW B13
P2.10.29 uCW B14
P2.10.30 uCW B15
24-hour support: +358 (0)201 212 575 • Email: vacon@vacon.com
Table 39.
Min Max Unit
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 10000
0 2
105.00 320.00 %
105.00 320.00 %
0 8
0.00 2000.15
0.00 2000.15
0.00 2000.15
0.00 2000.15
0 10000
0 10000
0 10000
0 10000
Fieldbus, G2.10
Default ID
44 1853
1104 852
1508 853
1172 854
1173 855
56 856
1174 857
1125 858
1157 859
0 876
0 877
0 878
0 879
0 880
0 881
0 882
0 883
68 897
0 = Basic
2 896 1 = Standard
2 = Vacon AFE 1
105.00 850
130.00 851
0 1440
0.00 1907
0.00 1908
0.00 1909
0.00 1910
0 1934
0 1935
0 1936
0 1937
vacon · 51
