42 · vacon
4.5.2

Delayed DO 1

Code Parameter
P2.5.2.1 Dig.Out 1 Signal
P2.5.2.2 DO1 Content
P2.5.2.3 DO1 ON Delay
P2.5.2.4 DO1 OFF Delay
P2.5.2.5 ID.Bit Free DO
4.5.3

Delayed DO 2

Code Parameter
P2.5.3.1 Dig.Out 2 Signal
P2.5.3.2 DO2 Content
P2.5.3.3 DO2 ON Delay
P2.5.3.4 DO2 OFF Delay
P2.5.2.5 ID.Bit Free DO
4
Table 16. Delayed DO 1, G2.3.2
Min Max Unit
0.1 E.10
0 10
0.00 320.00 s
0.00 320.00 s
0.00 2000.00 ID.Bit
Table 17. Delayed DO 2, G2.3.3
Min Max Unit
0.1 E.10
0 10
0.00 320.00 S
0.00 320.00 S
0.00 2000.00 ID.Bit
Tel. +358 (0)201 2121 • Fax: +358 (0)201 2121 205
Default ID Description
Connect the delayed DO1
signal to the digital output of
0.1 486
your choice with this
parameter.
0 = Not used
1 = Ready
2 = Run
3 = Fault
4 = Fault inverted
5 = FC overheat warning
6 = Ext. fault or warning
7 = Ref. fault or warning
0 312
8 = Warning
9 = Reverse
10 = SynchronisedToD7
11 = Start Command given
12 = FB DIN2
13 = FB DIN3
14 = ID.Bit DO
0.00 487 0.00 = On delay not in use
0.00 488 0.00 = On delay not in use
0.00 1216
Default ID Description
Connect the delayed DO2
signal to the digital output of
0.1 486
your choice with this
parameter.
0 = Not used
1 = Ready
2 = Run
3 = Fault
4 = Fault inverted
5 = FC overheat warning
6 = Ext. fault or warning
0 312 7 = Ref. fault or warning
8 = Warning
9 = Reverse
10 = SynchronisedToD7
11 = Start Command given
12 = FB DIN2
13 = FB DIN3
14 = ID.Bit DO
0.00 487 0.00 = On delay not in use
0.00 488 0.00 = On delay not in use
0.00 1217
Parameter list
