Analogue Input 4; Output Signals; Digital Output Signals - Danfoss Vacon NXP Applications Manual

Parameter list
4.4.6

Analogue input 4

Code Parameter
P2.4.6.1 AI4 signal selection
P2.4.6.2 AI4 filter time
AI4 custom
P2.4.6.3
minimum setting
AI4 custom
P2.4.6.4
maximum setting
P2.4.6.5 AI4 signal inversion
AI4 reference
P2.4.6.6 scaling, minimum
value
AI4 reference
P2.4.6.7 scaling, maximum
value
P2.4.6.8 AI4 Controlled ID
4.5

Output signals

4.5.1

Digital output signals

Code Parameter
P2.5.1.1 MCB1 Close Control
P2.5.1.2 MCB1 Open Control
P2.5.1.3 Ready
P2.5.1.4 Run
P2.5.1.5 Common Fault
P2.5.1.6 Fault, Inverted
P2.5.1.7 At reference
Overtemperature
P2.5.1.8
Warn.
P2.5.1.9 Warning
P2.5.1.10 CB2 Close Control
P2.5.1.11 NET Contactor
P2.5.1.12 D7 Synchronized
P2.5.1.13 Charge Control
P2.5.1.14 Common Alarm
P2.5.1.15 Ready For Start
P2.5.1.16 Quick Stop Active
P2.5.1.17 Fieldbus digital input 1
P2.5.1.18 FB Dig 1 Parameter
P2.5.1.19 Fieldbus digital input 2
P2.5.1.20 FB Dig 2 Parameter
P2.5.1.21 Fieldbus digital input 3
P2.5.1.22 FB Dig 3 Parameter
P2.5.1.23 Fieldbus digital input 4
P2.5.1.24 FB Dig 4 Parameter
24-hour support: +358 (0)201 212 575 • Email: vacon@vacon.com
Table 14. Analogue Input 2, G2.2.3
Min Max Unit
0.1 E.10
0.000 32.000 s
-160.00 160.00 %
-160.00 160.00 %
0 1
-32000 32000
-32000 32000
0 10000
Table 15. Digital output signals, G2.3.1
Min Max Unit
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 E.10
0.1 0.1
ID0 ID0
0.1 0.1
ID0 ID0
0.1 0.1
ID0 ID0
0.1 0.1
ID0 ID0
Default ID Description
0.1 152
0.000 153
0.00 155
100.00 156
0 162
0 1039
0 1040
0 1510
Default ID Description
AFE contactor, fixed to relay
0.1 1218
output B.2
0.1 1219
The AC drive is ready to
0.1 432
operate.
The AC drive operates (the
0.1 433
motor is running).
0.1 434 A fault trip has occurred.
0.1 435 No fault trip has occurred.
0.1 442
The heatsink temperature
0.1 439
exceeds +70 °C
0.1 436 General warning signal.
Second AFE contactor
0.1 1709
control
0.1 1605 NET contactor ( DC )
Drive is synchronised to D7
0.1 1753
card
Charge control from start
0.1 1568
command
0.1 1684
No conditions that could
0.1 1686
disable starting active
0.1 1687
0.1 455 FB CW B11
891 Select parameter to control
0.1 456 FB CW B12
892 Select parameter to control
0.1 457 FB CW B13
893 Select parameter to control
0.1 169 FB CW B14
894 Select parameter to control
