Danfoss Vacon NXP Applications Manual page 30

28 · vacon
V1.3.3 Fault Word 1
b0
b1
b2
b3
b4
b5
b6
b7
b8
b9
b10
b11
b12
b13
b14
b15
V1.3.4 Fault Word 2
b0
b1
b2
b3
b4
b5
b6
b7
b8
b9
b10
b11
b12
b13
b14
b15
3
ID 1172
FALSE
F1 Over current, F31 IGBT, F41 IGBT
F2 Over Voltage
F9 Under Voltage
F91 Short Circuit
F3 Earth Fault
F14 Unit Over temperature
Temperature fault from measurements F56 PT100, F29 Thermistor
F10 Line Synch Fault
F52 Keypad or OC communication fault
F53 Fieldbus fault
F59 System bus fault
F54 Slot Communication fault
F50 4mA fault
ID 1173
FALSE
F11 Output Phase Fault
F51 External fault
F31 IGBT, F41 IGBT
F64 MCB State fault
TRUE
TRUE
Tel. +358 (0)201 2121 • Fax: +358 (0)201 2121 205
Monitoring signals
