  • Page 1 MAKING MODERN LIVING POSSIBLE Quick Guide ® 2800 www.danfoss.com/drives...
  • Page 3: Table Of Contents

    4.10 EMC Emission 4.11 Extra Protection 4.12 EMC-Correct Electrical Installation 4.13 Fuses 4.14 RFI Switch (VLT 2880-2882 Only) 5 Control Panel Operations 5.1 Programming 5.1.1 Control Unit 5.1.2 Control Keys 5.1.3 Manual Initialisation MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 4 7.3.2 Derating for Ambient Temperature 7.3.3 Derating for Low Air Pressure 7.3.4 Derating for Running at Low Speeds 7.3.5 Derating for Long Motor Cables 7.3.6 Derating for High Switch Frequency Index Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 5: Introduction

    ® is a registered trademark. Guide. 1.5 Disposal Do not dispose of equipment containing electrical components together with domestic waste. Collect it separately in accordance with local and currently valid legislation. MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 6: Safety

    • Installation, start-up, and maintenance must be performed by qualified personnel only. Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 7 For details about the use of the frequency converter on isolated mains, refer to section RFI Switch in the Design Guide. Follow the recommendations regarding the installation on IT-mains. Use relevant monitoring devices for IT- mains to avoid damage. MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 8: Mechanical Installation

    Quick Guide 3 Mechanical Installation 3.1 Overview VLT 2800 frequency converters allow side-by-side instal- lation on a wall in any position as the units do not require ventilation on the side. Because of the need for cooling, there must be 100 mm free air passage above and below the frequency converter.
  • Page 9: Motor Coils (195N3110) And Rfi 1B Filter (195N3103)

    Fit the decoupling plate to the power cables and the ground screw (terminal 95). 3.2 Motor Coils (195N3110) and RFI 1B Filter (195N3103) Illustration 3.3 Motor Coils (195N3110) Illustration 3.4 RFI 1B Filter (195N3103) MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 10: Terminal Cover

    VLT 2822, PD2 VLT 2855-2875, 380-480 V VLT 2880-2882, 380-480 V 195N2126 47 VLT 2840, PD2 Table 3.2 Dimensions Illustration 3.6 NEMA 1 Terminal Cover Illustration 3.8 Dimensions for IP 21 Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 11: Emc Filter For Long Motor Cables

    Mechanical Installation Quick Guide 3.5 EMC Filter for Long Motor Cables Illustration 3.9 Filter Dimensions Filter Dimensions øa 27.5 192H4719 øb øa 192H4720 øb 192H4893 øa øb Table 3.3 Filter Dimensions MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 12: Electrical Installation

    The power terminals can be removed. Connect mains to the mains terminals of the frequency converter, i.e. L1, L2 and L3 and the ground connection to terminal 95. Illustration 4.1 Terminals Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 13 U, V, W. The screen ends in a screen connector. Illustration 4.4 VLT 2840, 200-240 V VLT 2822, 200-240 V - PD2 VLT 2855-2875, 380-480 V MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 14: Mains Connection

    See chapter 7.2 General Specifications for correct dimensioning of cable cross-section. All types of 3-phase asynchronous standard motors can be connected to a frequency converter. Normally, small motors are star-connected (230/400 V, Δ/Y). Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 15: Motor Cables

    If it is necessary to break the screen to cables. install a motor isolator or motor relay, the screen must be continued at the lowest possible HF impedance. Illustration 4.8 Control Cable Connection MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 16: Grounding

    Table 4.5 Relay Contacts NOTICE The cable jacket for the relay must cover the first row of control card terminals - otherwise the galvanic isolation (PELV) cannot be maintained. Max. cable diameter: 4 Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 17: Emc Emission

    RCD or a manually operated switch is used to connect the frequency converter to the mains voltage, a time delay of minimum 40 ms is required (RCD type B). MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 18: Emc-Correct Electrical Installation

    (pigtails), since this ruins the screening effect at high frequencies. Use cable clamps instead. • It is important to ensure good electrical contact from the installation plate through the installation Illustration 4.9 Example of an EMC-correct Electrical Installation Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 19: Fuses

    480 V maximum. Short circuit protection Danfoss recommends using the fuses mentioned in If UL/cUL is not to be complied with, Danfoss recommends Table 4.7 to protect service personnel and equipment in using the fuses mentioned in Table 4.7, which ensures case of an internal failure in the unit or short-circuit on compliance with EN50178/IEC61800-5-1.
  • Page 20: Control Panel Operations

    [1] Locked via parameter 018 Lock for [CHANGE DATA] while simultaneously reconnecting the data changes. mains voltage. Release the keys; the frequency converter is now programmed for the factory setting. Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 21: Display Readout States

    Motor power [kW] - Parameter 102 • Motor voltage [V] - Parameter 103 • Motor frequency [Hz] - Parameter 104 • Motor current [A] - Parameter 105 • Rated motor speed - Parameter 106 MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 22: Motor Start

    [QUICK MENU] and [+] keys must be pressed simulta- neously to give access to all parameters. 5.3 Connection Examples ® More examples can be found in the VLT 2800 Design Guide. Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 23: Mg28M202 Danfoss A/S © Rev. 2014-03-18 All Rights Reserved

    Control Panel Operations Quick Guide MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 24 Control Panel Operations Quick Guide Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 25 Control Panel Operations Quick Guide MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 26 Control Panel Operations Quick Guide Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 27: Troubleshooting

    Warning is given while AMA is performed. DURING AMT) Locked (LOCKED) See parameter 018 Lock for data changes. Table 6.1 Warning and Alarm Messages W: Warning A: Alarm T: Trip locked MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 28 After a trip, the motor coasts, and both alarm and warning flash on the frequency converter. If the fault disappears, only the alarm flashes. After a reset the frequency converter is ready to start operation again. Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 29: Specifications

    20/20 20/20 20/20 Efficiency Power loss at 100% load Weight [kg] Enclosure type IP 20 IP 20 IP 20 IP 20 IP 20 IP 20 Table 7.2 Mains Supply 380-480 V MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 30: General Specifications

    Overload torque (parameter 101 Torque characteristic = Constant torque) 160% Overload torque (parameter 101 Torque characteristic = Variable torque) 160% Percentage relates to frequency converter's nominal current. 1) VLT 2822 PD2/2840 PD2 1x220 V only 110% in 1 min Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 31 Max. error: 0.1% of full scale The pulse input (terminal 33) is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. See section Galvanic Isolation in the Design Guide. MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 32 Terminal number 70 Common for terminals 67, 68 and 69 Full galvanic isolation. See section Galvanic Isolation in the Design Guide. For DeviceNet units, see VLT 2800 DeviceNet manual. Relay outputs Number of programmable relay outputs Terminal number, control card (resisitvie and inductive load) 1-3 (break), 1-2 (make) Max.
  • Page 33 Temperature monitoring of the power module ensures that the frequency converter cuts out if the temperature reaches 100 °C. An overload temperature cannot be reset until the temperature of the power module is below 70 °C. MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 34: Special Conditions

    7.3.3 Derating for Low Air Pressure Above 1,000 m the ambient temperature or max. output current must be derated. For altitudes above 2,000 m, contact Danfoss regarding PELV. Danfoss A/S © Rev. 2014-03-18 All rights reserved. MG28M202...
  • Page 35: Index

    IT mains....................17 Leakage current..................5 Mains connection................. 12 Mechanical installation................. 6 Menu mode.................... 19 Motor cable..................... 13 Motor coil....................7 Motor connection................. 12 Motor thermal protection..............13 Motors, parallel connection.............. 12 MG28M202 Danfoss A/S © Rev. 2014-03-18 All rights reserved.
  • Page 36 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
