7. FB Status and control in detail

P2.10.19 State machine
1 / Basic
2 / Standard
3 / Vacon AFE 1
7.1

FB DC Reference

Fieldbus DC reference is available when the Grid Converter is in fieldbus control.The format is the
same as in panel references. (11000 = 110 %). If reference is not used from fieldbus, set the
"FBSpeedReference" to zero. When FB reference is zero, the drive will use DC Voltage Reference
from keypad parameter.
7.2

State machine: Basic

7.2.1

FB Control Word Basic

FALSE
b0 Stop Request
b1
b2 No Action
b3 Fieldbus DIN1=OFF
b4 Fieldbus DIN2=OFF
b5 Fieldbus DIN3=OFF
b6 Fieldbus DIN4=OFF
b7
b8
b9
b10
b11
b12
b13
b14
b15
B00: FALSE = Stop Request, TRUE = Start Request
Stop Request: Drive will stop modulating
Start Request: Drive will start modulating, rising edge needed after fault situation.
7
This mode makes fieldbus control operate as is explained in the
fieldbus board manual.
Simple control word that is used in modes where the control word
from fieldbus is used as such. For some fieldbus boards this
requires bypass operation.
This mode uses a ProfiDrive type state machine in the application
level. It is possible to use this mode on fieldbus boards that do not
have a state machine or have a possibility to bypass the state
machine function on the option board.
Table 51.
FB Control Word: Basic
TRUE
Start Request
Fault Reset 0 > 1
Fieldbus DIN1=ON
Fieldbus DIN2=ON
Fieldbus DIN3=ON
Fieldbus DIN4=ON
FB Status and control in detail
Comment
Use this for start and stop command
Use this for fault reset
See P2.5.1.17 -18
See P2.5.1.19 -20
See P2.5.1.21 -22
See P2.5.1.23 -24
