Air Cooled 500 Vac Units, 465-800 Vdc; Air Cooled 690 Vac Units, 640-1100 Vdc; Liquid Cooled 500 Vac Units, 465-800 Vdc; Liquid Cooled 690 Vac Units, 640-1100 Vdc - Danfoss Vacon NXP Applications Manual

18 · vacon
1.14.1

Air cooled 500 Vac Units, 465-800 Vdc

Code + MASG
NXA_0261 5 A0T02SG
NXA_0460 5 A0T02SG
NXA_1300 5 A0T02SG
1.14.2

Air Cooled 690 Vac Units, 640-1100 Vdc

Code + MASG
NXA_0170 6 A0T02SG
NXA_0325 6 A0T02SG
NXA_1030 6 A0T02SG
1.14.3

Liquid Cooled 500 Vac Units, 465-800 Vdc

Code + MASG
NXA02615A0T02WV
NXA03855A0T02WG
NXA05205A0T02WG
NXA07305A0T02WG
NXA09205A0T02WG
NXA11505A0T02WG
NXA16405A0T02WG
NXA23005A0T02WG
1.14.4

Liquid Cooled 690 Vac Units, 640-1100 Vdc

Code + MASG
NXA02616A0T02WG
NXA03856A0T02WG
NXA05026A0T02WG
NXA07506A0T02WG
NXA11806A0T02WG
NXA15006A0T02WG
NXA17006A0T02WG
1.14.5

Liquid Cooled 690 Vac Units, 640-1200 Vdc

Code + MASG
NXA02618A0T02WG
NXA03858A0T02WG
NXA05028A0T02WG
NXA07508A0T02WG
NXA11808A0T02WG
NXA15008A0T02WG
NXA17008A0T02WG
1
Frame IL-cont [A]
1xFI9 261
1xFI10 460
1xFI13 1300
Frame IL-cont [A]
1xFI9 170
1xFI10 325
1xFI13 1030
Chassis Ith [A]
CH5 261
CH61 385
CH62 520
CH62 730
CH63 920
CH63 1150
CH64 1640
CH64 2300
Chassis Ith [A]
CH61 261
CH62 385
CH62 502
CH63 750
CH64 1180
CH64 1500
CH64 1700
Chassis Ith [A]
CH61 261
CH62 385
CH62 502
CH63 750
CH64 1180
CH64 1500
CH64 1700
IH-cont [A] Is [A] (2 s)
205 349
385 693
1150 2070
IH-cont [A] Is [A] (2 s)
144 245
261 470
920 1656
Il [A] Ih [A]
237 174
350 257
473 347
664 487
836 613
1045 767
1491 1093
2091 1533
Il [A] Ih [A]
237 174
350 257
456 335
682 500
1073 787
1364 1000
1545 1133
Il [A]
237
350
456
682
1073
1364
1545
Tel. +358 (0)201 2121 • Fax: +358 (0)201 2121 205
General
Is [A]
261
385
520
730
920
1150
1640
2300
Is [A]
261
385
502
750
1180
1500
1700
Ih [A] Is [A]
174 261
257 385
335 502
500 750
787 1180
1000 1500
1133 1700
