Clock Spring Adjustment - Mazda RX-8 Manual

6. Install in the reverse order of removal.
7. Turn the ignition switch to the ON position.
8. Verify that the air bag system warning light illuminates for approx. 6 s and goes out.
If the air bag system warning light does not operate normally, refer to the on-board diagnostic
•
system (air bag system) and perform inspection of the system.
Clock Spring Installation Note
CAUTION:
If the clock spring is not adjusted, the spring wire in the clock spring could over-wind and break when
•
the steering wheel is turned. Always adjust the clock spring after installing it.
1. Adjust the clock spring after installing it. (See CLOCK SPRING ADJUSTMENT .)

CLOCK SPRING ADJUSTMENT

NOTE:
The adjustment procedure is also specified on the caution label of the clock spring.
•
1. Set the front tires straight-ahead.
CAUTION:
The clock spring will break if over-wound. Do not forcibly turn the clock spring.
•
2. Turn the clock spring clockwise until it stops.
