lite blue.
™
MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Vanderbilt lite blue

Summary of Contents for Vanderbilt lite blue

  • Page 1 ™ MANUAL...
  • Page 2 Information contained in this manual is subject to change without notice and does not represent any commitment on the part of Vanderbilt Industries. Vanderbilt Industries assumes no responsibility or liability for any errors or inaccuracies that may appear in this documentation.

  • Page 3: Table Of Contents

    Contents Contents Vanderbilt Industries Copyright Notice UL Listing Summary Compatible UL evaluated equipment ........................9 Hardware Not UL Evaluated..........................9 Firmware Designation ............................10 UL Evaluated Firmware ............................10 The following should be incorporated into the system: ..................10 Operation Testing and Maintenance ........................10 Operation Testing ...........................
  • Page 4 Static IP Configuration (Recommended) ....................27 DHCP Configuration ..........................33 lite blue Date and Time Setup ..........................35 Using the lite blue software to set date and time..................35 Using the Discovery and Configuration Tool to set date and time............38 Battery Replacement ............................41 VBB-RI Overview ................................
  • Page 5 VBB-RI Pin Layout ............................. 45 VBB-RI Pin Functions ..........................46 Pins Left at Default ..........................46 Pins Not Used ............................47 Connecting to lite blue ............................47 Powering VBB-RI ............................ 48 Addressing the VBB-RI ........................... 48 Connecting to Read Head ..........................49 Recommended Wire Chart: VBB-RI to Reader Head ................
  • Page 6 Environmental conditions ........................60 Mounting ..............................60 SBB-RI Pin Layout ............................. 61 SBB-RI Pin Functions ..........................61 Connecting to lite blue ............................63 Powering SBB-RI ............................ 63 Addressing the SBB-RI ........................... 64 Connecting to Read Head ..........................64 Recommended Wire Chart: SBB-RI to Reader Head ................64 P3 - SBB-RI pin connections ........................
  • Page 7 Panel Interface Module (PIM400-485-VBB) .................... 96 AD-400 Series Wireless Locks........................ 97 WRI400 ..............................99 Wiring Instructions ............................100 Wiring between lite blue and PIM400 (legacy) ..................100 Wiring between lite blue and PIM400 (new) ..................101 PIM400 Configuration ............................101 Log In to SUS............................102 Pair to PDA ............................
  • Page 8 WA Series Locks (WA) ......................... 118 Wireless Reader Interface (WRI – Indoor or Outdoor) ................121 Wiring instructions ............................122 Wiring between lite blue and PIM Module ..................... 123 Wireless reader modules configuration ....................123 Device capacities ..........................124 Linking and addressing locks to the PIM ....................124 Installing the CDT software ........................
  • Page 9 Contents Configuration ..............................134 Viewing lite blue Transaction Alarms ....................... 140 Searching for lite blue Transaction Alarms ....................... 143 Troubleshooting Overview ................................145 Device Communication ............................ 145 VBB-RI Addressing Issues ........................145 Wiring Problems ............................ 145 Upgrading Software ............................146 Manually Unlock Doors for Upgrade .....................

  • Page 10: Ul Listing Summary

    VBB-NRI  SBB-RI (Legacy) XCEED-ID Equipment  XF1050 Supported Proximity Cards  Standard 26-bit Wiegand Format  Vanderbilt 34-bit Wiegand Format  HID Corporate 1000 35-bit  HID Corporate 1000 48-bit  HID/ProxIF 37-bit  XceedID 40-bit  XceedID 35-bit Note: All interconnected devices (panic hardware, REX, alarm devices, door contacts, computers, wiring, etc.)

  • Page 11: Firmware Designation

    Operation Testing and Maintenance Operation Testing Once lite blue and system components are installed, log into the system and set up a cardholder with a credential and access. Present that credential at read head to test. A green LED indicates system is working.

  • Page 12: Declaration Of Conformity

    Certify that the equipment described below conforms with the essential requirements of the following European Directive: Electromagnetic Compatibility (EMC) 2004/108/EC Conforming Apparatus VLB Vanderbilt lite blue Reader Controller VBB-NRI Vanderbilt bright blue Network Reader Interface VBB-RI Vanderbilt bright blue Reader Interface Serial Numbers...

  • Page 13: Preface

    12 lite blue Installation Manual Preface This manual describes the installation and wiring procedures for the lite blue controller and peripheral devices. Who should use this book This installation manual provides guidelines for installing and configuring the lite blue controller and the hardware that interfaces with it.

  • Page 14: Symbols And Conventions

    Disclaimer: Disclaimers provide information that should be considered by the technician. U.S./International Technical Support If any problems are encountered while installing or operating lite blue, please contact our technical support team for assistance. U.S. Vanderbilt Technical Support: Phone: 855-316-3900 International Vanderbilt Technical Support: Phone: 973-316-3900 Vanderbilt Technical Support: E-mail: techsupport@vanderbiltindustries.com...

  • Page 15: Before Installation

    14 lite blue Installation Manual Before Installation This section provides information on what should be considered before installing the lite blue hardware. Requirements  Check to see that all the equipment necessary for the installation is on hand. Make sure all the necessary tools to properly install the equipment, i.e.

  • Page 16: Environmental Consideration

    Before Installation Environmental Consideration lite blue (VLB), the VBB-NRI and the VBB-RI must be installed indoors within the protected premises in a  clean and a dust free environment.  Ambient temperature: 32F to 120F (0 C to 49C) ...

  • Page 17: Web Browser Requirements

    Chrome. Compatibility with requires the use of the IE Tab Chrome Extension. Chrome has not been tested on the Mac OS X operating system. lite blue uses ports 80 and 443 to communicate; these ports cannot be blocked by any firewall. Note:...

  • Page 18: Device Power Requirements

    Example 2: lite blue One power supply is going to be used to power 6 Schlage AD-300 locks, 2 VBB-RIs and Schlage AD locks require 300mA, VBB-RIs require 300mA, lite blue requires 250mA   300mA x 6 = 1800mA (for the AD 300s) ...

  • Page 19: Lite Blue

    Vanderbilt lite blue Embedded Controller Overview The lite blue system is based on a Mercury EP4502 controller and is equipped with 10 / 100 Base-T Ethernet connection with two RS-485 serial ports and two onboard reader interfaces capable of Wiegand or Magstripe input.

  • Page 20: Highlights

    Additional devices must be powered independently from the lite blue controller. If a single power supply is used, it must be large enough to power the lite blue controller and all attached devices. Make sure that the total power requirements for all devices does not exceed the output of the power supply(s) in use (see specific device chapters for power requirements).

  • Page 21: Power Method 1 - Single Power Supply

    Connect power to all external devices independently as needed. Turn on the power supply to lite blue and any additional power supplies. Configure the lite blue IP address, date and time. See the lite blue IP Configuration and lite blue Date and Time setup section for details.

  • Page 22: Enclosure Installation

    Enclosure Installation lite blue - An enclosure with a hinged door and a lock is included with each lite blue system. The Enclosure flying leads of the tamper switch should be attached to a UL Listed burglar alarm system or Listed local siren/annunciator.

  • Page 23: Lite Blue Pin Layout

    22 lite blue Installation Manual lite blue Pin Layout lite blue Pin Functions Power input for lite blue. 12VDC or 24VDC. TB1:  GND (-)  Shutdown / Restart  FLT (+)  Shutdown / Restart  GND (-)  Tamper ...

  • Page 24: Functions On Mercury Controller

    Chapter 1 lite blue RESET / SHUTDOWN - Hold for 5 - 9 seconds and release for Reboot. Hold for 10 seconds for Power Down. Refer to LED Indicators. Functions On Mercury Controller - micro SD connection for flash memory.
  • Page 25 24 lite blue Installation Manual DO NOT USE - RESET -- DO NOT REMOVE. [CPU Daughter Board] - [CPU Daughter Board] - RS-232 DO NOT USE [CPU Daughter Board] - RESET -- Never Depress the S2 RESET button on the main controller or S1 RESET button on the CPU daughter board.
  • Page 26 Chapter 1 lite blue OUT 2 - Relay Output 2 for Reader 1  Normally Open  Common  Normally Closed OUT 3 - Relay Output 1 for Reader 2  Normally Open  Common  Normally Closed OUT 4 - Relay Output 2 for Reader 2 ...

  • Page 27: Lite Blue Led Indicators

    Not Used (Reserved for future use) IP Address Configuration:  On = Vanderbilt Default IP (192.168.168.250) assigned  Off = IP Address Changed from Vanderbilt Default Shutdown / Restart Operation:  Blinking = Button monitoring process active - Normal  Rapid Blinking = Button depressed - Restart on release ...

  • Page 28: Lite Blue Ip Configuration

    IP Configuration The IP address of lite blue has to be configured so that it can communicate with a web browser. Configuration should occur after the controller is fully installed. There are two methods to configure the IP address: Static IP and DHCP which are detailed below.
  • Page 29 28 lite blue Installation Manual Network Connections Click on . The Network Connections window will open. Local Area Connection Click on . The Local Area Connection Properties window will open. Internet Protocol (TCP/IP) Scroll down and select Properties Click the...
  • Page 30 Chapter 1 lite blue Make a note of the existing settings. These will need to be restored at the end of the lite blue configuration process to return the PC to its usual settings. Use the following IP address Click on the button.
  • Page 31 30 lite blue Installation Manual If dip switch 1 of S1 on the lite blue controller is in the "ON" position then this window will open: Continue to this website (not This message is not an error and should be bypassed. Click on recommended) The lite blue home page will open.
  • Page 32 Chapter 1 lite blue button. The lite blue main window will open. Log In Click on the Utilities Click on the button on the left side of the screen. The System Utilities window will open. VLBIM06/15/15 v4.1.0...
  • Page 33 Save Changes 10 Click on the button. The Utilities - Network Settings pop-up window will open. button. The connection to lite blue will be lost as the network settings are updated. Continue 11 Click on the...

  • Page 34: Dhcp Configuration

    14 Restore the network settings on the PC (follow step 2 above to access the network settings of the PC). 15 Open a web browser. 16 Enter http:// followed by the new IP address into the browser. The lite blue home page will open and lite blue's IP address is successfully configured.
  • Page 35 34 lite blue Installation Manual Run the Discovery and Configuration tool. button to search for lite blue controllers. Click on the Edit the default values. Select which controller to configure. Device Configuration Click on the button. The Device Configuration window will open.

  • Page 36: Lite Blue Date And Time Setup

    Date and Time Setup The date and time for lite blue has to be set up for the system to work properly. The date and time can be entered in two ways: 1) Through the lite blue software. 2) Using the Discovery and Configuration Tool as described below.
  • Page 37 36 lite blue Installation Manual If dip switch 1 of S1 on the lite blue controller is in the "ON" position then this window will open: Continue to this website (not This message is not an error and should be bypassed. Click on recommended) The lite blue home page will open.
  • Page 38 Chapter 1 lite blue button. The lite blue main window will open. Log In Click on the Utilities Click on the button on the left of the main screen. The System Utilities window will open. VLBIM06/15/15 v4.1.0...

  • Page 39: Using The Discovery And Configuration Tool To Set Date And Time

    The system time, date, and time zone will be updated. Using the Discovery and Configuration Tool to set date and time Connect the PC running the Discovery and Configuration tool to the lite blue controller.  Direct Connection - Using a cross-over cable, the controller can be connected directly to the network...
  • Page 40 Network Connection - Using a regular network cable, the controller can be connected to a hub or switch that is on the same network as the PC. Run the Discovery and Configuration tool. button to search for lite blue controllers. Click on the VLBIM06/15/15 v4.1.0...
  • Page 41 40 lite blue Installation Manual Select the lite blue controller and click on the Device Configuration button. The Device Configuration window will open. Click on the Clock tab. Click on the Set the Clock To button. Click on the Synchronize clock to this computer check box to select it.

  • Page 42: Battery Replacement

    Chapter 1 lite blue Battery Replacement The lite blue controller uses a UL Listed Sanyo CR2330 or equivalent 3V Lithium Coin Cell battery. The battery should be replaced every year. To replace the battery: lite blue Hold the RESET/SHUTDOWN Switch for at least 10 seconds.

  • Page 43: Vbb-Ri

    Reader Interface Overview The VBB-RI is a Reader Interface between lite blue and card readers. The VBB-RI offers a cost-effective, modular approach to access control system design. Reader Interfaces can connect to a variety of different read head technologies supported by lite blue. These include both Magnetic Stripe (not evaluated by UL) and...

  • Page 44: Highlights

    Must be powered locally by an external power supply. Features  Supports one read-head credential Connects directly to the communication channels on the lite blue controller via RS-485 protocol   Includes Two 2 amp, form C, single pole/double throw, mechanically latching relay ...

  • Page 45: Vbb-Ri Enclosure

    44 lite blue Installation Manual VBB-RI Enclosure VBB-RI Enclosure - An enclosure with a hinged door is included for each VBB-RI. The flying leads of the tamper switch should be attached to a UL Listed burglar alarm system or Listed local siren/annunicator.

  • Page 46: Environmental Conditions

    Chapter 2 VBB-RI Environmental conditions  Ambient Temperature: 0º to 49º C or 32º to 120º F  The room must be dust free and clean.  It is optimal to mount the enclosure on fire rated plywood which is affixed to a cinder block wall or a wall covering i.e.

  • Page 47: Vbb-Ri Pin Functions

    46 lite blue Installation Manual VBB-RI Pin Functions P4 - Power source and communication wiring. Used to connect lite blue to the VBB-RI.  Pin 1 is Ground (GND)  Pin 2 is Data B (TXB)  Pin 3 is Data A (RXA) ...

  • Page 48: Pins Not Used

    Data communication between the lite blue controller and a VBB-RI reader interface is via RS-485 protocol. Either RS-485 channel on the lite blue controller can be used to communicate with P4 on a VBB-RI. The below example is using RS485-1 on the lite blue controller and P4 on the VBB-RI.

  • Page 49: Powering Vbb-Ri

    W10 on the VBB-RI consists of four jumpers that can be combined to set the address for the device. Each VBB-RI on a lite blue controller RS-485 data channel must have a unique address (1 – 8). Make a note of the address of the VBB-RI and which channel it is connected to. This information will be required to set up the lock in the software.

  • Page 50: Connecting To Read Head

    Chapter 2 VBB-RI Connecting to Read Head The VBB-RI reader interface can communicate to many different read heads. Provided here are the pin outs for the most commonly used read-heads. The connection is different for each reader type. See the Recommended Wire Chart below for the proper wire type and lengths.

  • Page 51: Xceed Id Xf 1050 Proximity Reader

    50 lite blue Installation Manual XCEED ID XF 1050 Proximity Reader Proximity Read Head Pin Connections VBB-RI Proximity Reader PIN 1 (CLK) DATA 0 (GREEN) Pin 2 (DAT) DATA 1 (WHITE) Pin 3 (GND) GROUND (BLACK) Pin 4 (PWR) POWER (RED)

  • Page 52: Installing Diode For Lock Wiring - Relay

    Chapter 2 VBB-RI Installing Diode for Lock Wiring - Relay A diode is supplied with the VBB-RI which should be fitted across 12V and COM to protect the relay contacts. The lock is wired across 12V and COM. A 0V link to COM is then required to complete the circuit. This will be wired to NO or NC depending on lock type: Fail Open / Fail Closed (diagram above shows Fail Open).

  • Page 53: Vbb-Obri

    The VBB-OBRI is an onboard Reader Interface between lite blue and card readers. These 2 included Reader Interfaces can connect to a variety of different read head technologies supported by lite blue. These include both Magnetic Stripe (not evaluated by UL) and Proximity readers.

  • Page 54: Highlights

    Powered directly from lite blue  Features  Supports one read-head credential Mounted directly on the lite blue Mercury EP4502 Controller   Includes Two 2 amp, form C, single pole/double throw, mechanically latching relay  Connection for one multi-color LED for access granted or access denied indication ...

  • Page 55: Vbb-Obri Pin Layout

    54 lite blue Installation Manual VBB-OBRI Pin Layout Onboard Reader Interface Connections:  Reader 1 (OUT1, OUT2, IN1, IN2, IN3, IN4)  Reader 2 (OUT3, OUT4, IN5, IN6, IN7, IN8)

  • Page 56: Vbb-Obri Pin Functions

    Chapter 3 VBB-OBRI VBB-OBRI Pin Functions Reader 1 lite blue Reader 1 can be used to connect 1 card-reader to  Pin 1 is Ground (GND)  Pin 2 is DAT/D0 (Data 0)  Pin 3 is CLK/D1 (Data 1) ...

  • Page 57: Connecting To Lite Blue

    The VBB-OBRI are mounted onboard the VLB Mercury EP4502 Controller. No additional connection to is required. Addressing the VBB-OBRI The two VBB-OBRI readers are addressed using the lite blue software. Please refer to the lite blue User Manual under Door Setup. Connecting to Read Head The VBB-OBRI reader interface can communicate to many different read heads.

  • Page 58: Vbb-Obri Pin Connections

    Chapter 3 VBB-OBRI VBB-OBRI Pin Connections XCEED ID XF 1050 Proximity Reader Proximity Read Head Pin Connections VBB-OBRI Proximity Reader PIN 1 (GND) GROUND (BLACK) PIN 2 (DAT/D0) DATA 0 (GREEN) PIN 3 (CLK/D1) DATA 1 (WHITE) PIN 4 (BZR) NOT USED PIN 5 (LED) LED (ORANGE)

  • Page 59: Sbb-Ri (Legacy)

    Reader Interface (SBB-RI Legacy) Overview The Legacy SBB-RI is a Reader Interface between lite blue and card readers. The SBB-RI offers a cost-effective, modular approach to access control system design. Reader Interfaces can connect to a variety of different read head technologies supported by lite blue.

  • Page 60: Highlights

    Must be powered locally by an external power supply. Standard Features  Supports one read-head credential Connects directly to the communication channels on the lite blue controller via RS-485 protocol   Includes Two 2 amp, form C, single pole/double throw, mechanically latching relay ...

  • Page 61: Sbb-Ri Enclosure

    60 lite blue Installation Manual SBB-RI Enclosure SBB-RI Enclosure - An enclosure with a hinged door is included for each SBB-RI. The flying leads of the tamper switch should be attached to a UL Listed burglar alarm system or Listed local siren/annunicator.

  • Page 62: Sbb-Ri Pin Layout

    Chapter 4 SBB-RI (Legacy) SBB-RI Pin Layout SBB-RI Pin Functions P4 - Power source and communication wiring. Used to connect lite blue to the SBB-RI. VLBIM06/15/15 v4.1.0...
  • Page 63 62 lite blue Installation Manual  Pin 4 is Ground  Pin 3 is Data B  Pin 2 is Data A  Pin 1 is Power P1 - Contact Inputs. The SBB-RI has four unsupervised contact points. When connecting more than two contact inputs to Pin 8 (GND), a terminal strip to connect the common ground wires needs to be installed.

  • Page 64: Connecting To Lite Blue

    Data communication between the lite blue controller and a VBB-RI reader interface is via RS-485 protocol. Either RS-485 channel on the lite blue controller can be used to communicate with P4 on a VBB-RI. The below example is using RS485-1 on the lite blue controller and P4 on the VBB-RI.

  • Page 65: Addressing The Sbb-Ri

    W2 on the SBB-RI consists of four jumpers that can be combined to set the address for the device. Each SBB-RI on a lite blue controller RS-485 data channel must have a unique address (1 – 8). Make a note of the address of the SBB-RI and which channel it is connected to. This information will be required to set up the lock in the software.

  • Page 66: P3 - Sbb-Ri Pin Connections

    Chapter 4 SBB-RI (Legacy) P3 - SBB-RI pin connections XCEED ID XF 1050 Proximity Reader VLBIM06/15/15 v4.1.0...

  • Page 67: Magnetic Stripe Reader

    66 lite blue Installation Manual Proximity Read Head Pin Connections SBB-RI Proximity Reader PIN 1 (CLK) DATA 0 (GREEN) Pin 2 (DAT) DATA 1 (WHITE) Pin 3 (GND) GROUND (BLACK) Pin 4 (PWR) POWER (RED) Pin 5 (GRN) LED (ORANGE)

  • Page 68: Vbb-Nri

    The VBB-NRI is a Networked Reader Interface that communicates with lite blue via a network connection. The VBB-NRI offers a cost-effective, modular approach to access control system design. Networked Reader Interfaces can connect to a variety of different read head technologies supported by lite blue. These include both Magnetic Stripe and Proximity readers.

  • Page 69: Highlights

    Communicates via network protocol at 10Base-T  Powered locally by a UL294 Listed Power-Limited, Power Supply capable of 4 hours standby power. OPTIONAL - can be powered directly from lite blue. (See Cable Requirement Chart for details)  Standard Features ...

  • Page 70: Environmental Conditions

    VBB-NRI IP Configuration The IP address of the VBB-NRI has to be configured so that it can communicate with lite blue. Configuration should occur after the reader interface is fully installed. There are two methods to configure the IP address: Static IP and DHCP which are detailed below.
  • Page 71 70 lite blue Installation Manual Configure the PC's network settings to communicate with the VBB-NRI Start Click on the button. Control Panel Click on . The Control Panel window will open. Network Connections Click on . The Network Connections window will open.
  • Page 72 Chapter 5 VBB-NRI Local Area Connection Click on . The Local Area Connection Properties window will open. Internet Protocol (TCP/IP) Scroll down and select Properties Click the button. The Internet Protocol (TCP/IP) Properties window will open. Make a note of the existing settings. These will need to be restored at the end of the VBB-NRI configuration process to return the PC to its usual settings.
  • Page 73 72 lite blue Installation Manual Use the following IP address Click on the button. IP address Enter 192.168.168.200 into the field. Subnet mask Enter 255.255.255.0 into the field. Click on the button. The PC's network settings are now compatible with the default VBB-NRI.
  • Page 74 Enter a Secondary DNS server into the Secondary DNS server field. Consult with network technicians to get an address that is compatible with the existing network. Click on the Update button. Make a note of the IP address as it will be used in the lite blue Door Setup section.

  • Page 75: Dhcp Configuration

    74 lite blue Installation Manual The Static IP address of the VBB-NRI has been set. Note: The Static IP address can also be set using the Discovery and Configuration Tool. Follow the directions below for DHCP but select the Static IP configuration option and manually enter the IP address and Subnet mask.
  • Page 76 Chapter 5 VBB-NRI Click on the button to search for VBB-NRI. Edit the default values. Select which VBB-NRI to configure. If multiple VBB-NRIs are discovered, use the Serial Number to determine which to configure. Device Configuration Click on the button to open the Device Configuration window. Network Click on the tab.

  • Page 77: Configuration Gui (Graphic User Interface)

    76 lite blue Installation Manual Make a note of the IP Address, it will be used by the lite blue interface to configure the VBB-NRI. Exit the Discovery and Configuration program. The DHCP address of the VBB-NRI has been set.
  • Page 78 Chapter 5 VBB-NRI The Host Name is used to access and setup the VBB-NRI using Dynamic DNS in conjunction with DHCP. Consult with network technicians for details on setting up your network in this manner. DHCP - This setting sets up the VBB-NRI to use a DHCP server on your network (use only if you have a DHCP server on the network).

  • Page 79: Vbb-Nri Pin Layout

    78 lite blue Installation Manual  Locked - The relay will be deactivated when communication is lost. In most installations this will mean that the door will become secured.  Power On lite blue - This section is used to define the behaviour of Relay 1 while is reloading the VBB- NRI after a power loss.

  • Page 80: Vbb-Nri Pin Functions

    P1 - Power source wiring. Used to supply power to the VBB-NRI.  Pin 1 is Ground Pin 2 is RXA and is not used with lite blue  Pin 3 is TXB and is not used with lite blue ...

  • Page 81: Pins Left At Default

    80 lite blue Installation Manual  Pins 3&4 - Enable/Disable Telnet. Enabled by default. If jumpered together, Telnet is disabled  Pins 5&6 - Enable/Disable Discovery protocol. Enabled by default. If jumpered together, the Discovery protocol is disabled, meaning that the Discovery tool will NOT find the unit.

  • Page 82: Connecting To Lite Blue

    Connecting to lite blue There is no direct connection between the VBB-NRI and lite blue. They need to be on the same network and the proper IP address of the VBB-NRI needs to be entered when setting up the door (see the VBB-NRI IP Configuration section for details) for them to communicate.

  • Page 83: Connecting To Read Head

    82 lite blue Installation Manual Connecting to Read Head The VBB-NRI reader interface can communicate to many different read heads. Provided here are the pin outs for the most commonly used read-heads. The connection is different for each reader type. See the Recommended Wire Chart below for the proper wire type and lengths.

  • Page 84: Proximity Reader

    Chapter 5 VBB-NRI Proximity Reader Proximity Read Head Pin Connections VBB-NRI Proximity Reader PIN 1 (CLK) DATA 0 (GREEN) Pin 2 (DAT) DATA 1 (WHITE) Pin 3 (GND) GROUND (BLACK) Pin 4 (PWR) POWER (RED) Pin 5 (GRN) LED (ORANGE) Pin 6 (RED) NOT USED Pin 7 (IBT)

  • Page 85: Installing Diode For Lock Wiring - Relay

    84 lite blue Installation Manual Installing Diode for Lock Wiring - Relay A diode is supplied with the VBB-NRI which should be fitted across 12V and COM to protect the relay contacts. The lock is wired across 12V and COM. A 0V link to COM is then required to complete the circuit. This will be wired to NO or NC depending on lock type: Fail Open / Fail Closed (diagram above shows Fail Open).

  • Page 86: Verifying Upgrade/Checking Version Number

    Chapter 5 VBB-NRI Example: tftp -I 10.45.49.78 put image_r129_k1226.SriUpd (the name of the image will vary depending on the release of the firmware). You will receive the following message when the file is sent to the VBB-NRI. It may take a few minutes for the board to update to the latest firmware after the message is received.
  • Page 87 86 lite blue Installation Manual Example: http://10.45.49.65/index_ver.html Version Display Click on the button. The full SRI Application Version Display window will open. Check the Geomain_ nri field which displays what revision of firmware was loaded to the VBB-NRI during the upgrade. If the data in this field corresponds to the version upgrade, your upgrade is successful.

  • Page 88: Schlage Adaptable Ad-300 Series Locks

    The AD-300 Lock is an integrated, modular lock that includes all the standard peripheral devices at a secured door opening. AD-300 Locks can be integrated directly into the lite blue controller. The communication protocol is RS- 485 to any of the communication channels on the lite blue controller.

  • Page 89: Contacts And Pin Functions

    Communication between the lite blue controller and an AD-300 lock is via RS-485 protocol. Either RS-485 channel on the lite blue controller can be used to communicate with J1 on an AD-300 lock. The below example is using RS485-1 on the lite blue controller and J1 on the AD-300 lock.

  • Page 90: Addressing The Ad-300 Lock

    SUS Address Address After the AD-300 has been connected to the lite blue controller, make a note of the channel and address. This information will be required to set up the lock in the software. Schlage Utility Software User's Guide...
  • Page 91 90 lite blue Installation Manual Pairing Mode Put the AD-300 lock into (this is necessary for the PDA to be able to make changes to the lock's settings). Internal Push Button 10 Hold down the on the AD-300 lock. Internal Push Button...

  • Page 92: Schlage Vip Locks

    The Schlage VIP Lock is an integrated, modular lock that includes all the standard peripheral devices at a secured door opening. VIP Locks can be integrated directly into the lite blue controller. The communication protocol is RS-485 to any of the communication channels on the lite blue controller.

  • Page 93: Contacts, Relays, And Pin Functions

    - Used to set protocol type. To communicate with lite blue this must be switched to ON.  OFF - VIP protocol  ON - 'F' series protocol Dip Switch 7 MUST be switched to the ON position for the VIP lock to work with lite blue. Note:...

  • Page 94: Connecting To Lite Blue

    Communication between the lite blue controller and a VIP lock is via RS-485 protocol. Either RS-485 channel on the lite blue controller can be used to communicate with J3 on a VIP lock. The below example is using RS485-1 on the lite blue controller and J3 on the VIP lock.

  • Page 95: Addressing The Vip Lock

    Two VIP locks can have an identical VIP address if on different lite blue RS-485 data channels. After the VIP has been connected to the lite blue controller, make a note of the address. This information will be required to set up the lock in the software.

  • Page 96: Schlage Adaptable Ad-400 Series

    Schlage wireless devices can be seamlessly integrated to your lite blue system. The PIM400-485-VBB communicates directly to the lite blue controller via RS-485 protocol and can support up to 16 Schlage AD-400 Series locks. Specifications and guidelines for configuring the wireless devices are in the pages that follow.

  • Page 97: Schlage Ad-400 Components

    The PIM400-485-VBB can be integrated with the system, it works in conjunction with the AD-400 Locks. The PIM400-485-VBB module is hard wired directly to lite blue communication channels and communicates via RS-485 protocol. The PIM400-485-VBB can support up to 16 AD-400 locks.

  • Page 98: Ad-400 Series Wireless Locks

    Operational environment  Temperature: -35°C to +66°C  Humidity: 20% RH to 95% RH (non-condensing)  lite blue Operating Voltage: 12 to 24 VDC (Powered from or locally)  Power consumption: 300mA max. Radio frequency (RF) - The PIM400 includes an RF Transceiver ...
  • Page 99 98 lite blue Installation Manual  Card Thickness - 0.030 inches thick  ANSI/ISO Standards 7810, 7811 1/51 7812, and 7813 Card Reader - Proximity Reader  ANSI/BHMA A156.25 compliant  Compatible with HID proximity cards  Wiegand output ...

  • Page 100: Wri400

    Chapter 8 Schlage Adaptable AD-400 Series WRI400 lite blue The WRI400 is a networked access point controller that communicates with via RF through a mating Panel Interface Module (PIM400-485-VBB). It is designed to provide wireless connectivity to electronic access control components including credential readers, door position and request to exit switches.

  • Page 101: Wiring Instructions

    Wiring Instructions The PIM400 can be powered directly from any data channel of the lite blue controller that is supplying 12 to 24 VDC or separately from a local power supply. lite blue and the PIM400 communicate via RS-485 protocol.

  • Page 102: Wiring Between Lite Blue And Pim400 (New)

    RS-485 communications jumper, P5 which must be ON (jumper installed) for 2-wire RS-485 communication on P4. The below example is using RS485-1 on the lite blue board to P4 and P2 on the PIM400. Data Communication and Power between lite blue and PIM400...

  • Page 103: Log In To Sus

    102 lite blue Installation Manual Initial set up of the PIM400 requires the following:  Login to SUS  Pair to PDA  Set PIM400 Address Log In to SUS You must log in to the Schlage Utility Software (SUS) located on the included PDA. Follow the steps below to log...

  • Page 104: Set Pim400 Address

    0 to 15. A maximum of eight (8) AD-400 Locks can communicate with a PIM400 module on the same channel, with all reader types when used with lite blue. The address used by the PIM400 and AD-400 locks...
  • Page 105 104 lite blue Installation Manual Follow the steps below to Address the PIM and to set its LOW/HIGH range for AD-400 locks. Log in to SUS (see steps above). Connect the PDA to the PIM400 using the supplied USB cable.

  • Page 106: Ad-400 Series Lock Configuration

    Chapter 8 Schlage Adaptable AD-400 Series Using the keypad, set the address of the PIM400. Low Door On the option, use the up and down arrows to define the low address of the AD-400s that will communicate with this PIM400. High Door On the option, use the up and down arrows to define the high address of the AD-400s that will...
  • Page 107 106 lite blue Installation Manual PIM Properties Click on the option. Link Go to the tab. Select Door 10 Use the drop down menu to Set the address of the AD-400. This number will be the AD-400's address. Link 11 Click...

  • Page 108: Diagnostics

    Chapter 8 Schlage Adaptable AD-400 Series Schlage Internal Push Button Linking Mode button will blink as will the . The lock is now in Exit Request Lever Release Stop 13 Once the option is enabled, the AD-400 is now linked to this PIM400 with the specified address. Diagnostics Follow the steps below to determine if you have correctly Linked your AD-400 lock to your PIM400: Log in to SUS (see steps above).

  • Page 109: Wri400 Configuration

    108 lite blue Installation Manual Diagnostics Demo Mode Click on the option. The window will open. Select Door Using the drop down, select the door you wish to test. Status If the section shows , then you have successfully linked the AD-400.
  • Page 110 Chapter 8 Schlage Adaptable AD-400 Series Note: The WRI400 will send a tamper signal while the cover is off. Log in to the SUS software (refer to the SUS User Guide for log-in procedure). Note: USB Connection Make sure the HHD connection type is set to Connect the HHD to the WRI400 USB port (J5).
  • Page 111 110 lite blue Installation Manual Device Options Click on the button. PIM Properties Click on the option. Link Go to the tab. Select Door 10 Use the drop down menu to Set the address of the WRI400. This number will be the WRI400's address.

  • Page 112: Additional Configuration

    Chapter 8 Schlage Adaptable AD-400 Series 14 Press and hold the WRI400’s LINK button until the RX/TX LED blinks red and green. 15 When linking is successful, the RX/TX LED will blink to indicate the quality of the RF link. ...
  • Page 113 112 lite blue Installation Manual Change the default setting (10 Minutes) to 1 second to allow for a Door Forced or Door Held Open lite blue transaction to be read by and activate the auxiliary relay. Save Click Configure Request to Exit...
  • Page 114 Chapter 8 Schlage Adaptable AD-400 Series Correct Configuration Save Click Configure Door Position Switch Device Options WRI400 Click on once the connection steps above have been followed and is displayed at the bottom of the SUS screen. Lock Properties Click on Edit tab Click on the Door Position Switch...
  • Page 115 114 lite blue Installation Manual Active open Change the default setting of the Door Position Switch option to Delay Change the option to Retry Change the option to . When done the screen should look like the following image: Correct Configuration...

  • Page 116: Schlage Wireless Readers

    H A P T E R Wireless reader Overview Schlage wireless devices can be seamlessly integrated with lite blue. The PIM-SBB (Legacy) communicates directly to lite blue via RS-485 protocol and can support up to 8 Schlage wireless devices on lite blue. VLBIM06/15/15 v4.1.0...

  • Page 117: Abbreviations

    WAPM Wireless Reader Interface WAPM Schlage Wireless System Components There are various wireless devices that are used to integrate with lite blue. The Schlage wireless system contains two different types of modules:  One wireless panel interface module (PIM) ...

  • Page 118: Wireless Panel Interface Module - Pim-Sbb (Legacy)

    The PIM-SBB (Legacy) works in conjunction with several types of wireless peripherals devices. The PIM-SBB module is hard wired directly to the lite blue power and communication channels via RS-485 protocol. The PIM- SBB can support up to 8 wireless devices when used with lite blue.

  • Page 119: Schlage Wireless Modules

    Request-to-Exit sensor/switch, an optional Request-to-Enter sensor/ switch, a power supply (battery pack), and terminals for monitoring a door position switch/sensor, a card reader, and an RF transceiver for communicating with another RF transceiver in a Panel Interface Module (PIM) which interfaces with lite blue. Performance ...
  • Page 120 - Schlage WA Series Locks provide a way to lock or unlock a door and monitor access from a remote location. They are fail-safe from the protected side of the door. These locks are controlled by lite blue. Cylindrical Type WA5200 Series ...
  • Page 121 120 lite blue Installation Manual Radio Frequency (RF) - The PIM includes an RF Transceiver.  Spread spectrum  Direct sequencing spread spectrum  Frequency: 902-928 MHz  Data Rate: 62.5 kbps (half duplex)  Modulo 256 error detection ...

  • Page 122: Wireless Reader Interface (Wri - Indoor Or Outdoor)

    Wireless Reader Interface (WRI – Indoor or Outdoor) The WRI-IN/OUT-12VDC acts as a remote card reading device that communicates via RF with lite blue through a mating Panel Interface Module (PIM). The Schlage wireless modules are powered locally with 12 VDC power supply.

  • Page 123: Wiring Instructions

    All Schlage wireless devices should be powered with a 12VDC power supply. The PIM-SBB (Legacy) can be powered directly from any data channel of the lite blue controller that is supplying 12VDC or separately from a local power supply. lite blue and the PIM-SBB communicate via RS-485 protocol.

  • Page 124: Wiring Between Lite Blue And Pim Module

    A maximum of eight (8) wireless readers can communicate with a PIM module on the same channel, with all reader types when used with lite blue. Address can be 0 through 7 (panel number 0 to 7 in the CDT). Example - if a WAPM is configured as Panel 5 (door 5) using the CDT, then its corresponding address in lite blue is five (5).

  • Page 125: Device Capacities

    Relay 1 for the lock Relay 1 state will be reported back to lite blue   Relay 2 for Aux Relay Relay 2 state will not be reported to the lite blue   Contact 1 for REX – Normally Open, Non-supervised ...

  • Page 126: Installing Microsoft Java Virtual Machine

    Chapter 9 Schlage Wireless Readers Run wireless software A folder will be created called WirelessDemo. Select WirelessDemo.HTML and double click to open. If the screen looks like the one shown above, the CDT software has been successfully installed. Proceed to configure the PIM.

  • Page 127: Configuring Pim

    126 lite blue Installation Manual Advanced Go to the tab. Use Java 2x1.4.2-06 for <applet> (requires to start) Uncheck the option Click If there are any problems, restart the CDT application. Configuring PIM Link Mode The next step is defining the PIM address by placing the in to .
  • Page 128 (See the next step for details on address range.) Example: Channel 1 of lite blue will have two PIMs. One PIM will be interfacing with 5 WAPMs and the other will be interfacing with 6. The first PIM will have an Addr Lo of 0 and an Addr Hi of 4. The PIM Addr for this PIM will be 0.

  • Page 129: Configuring The Wri

    If multiple PIMs are being used on the same channel it is recommended that room be left in the addressing range for later expansion. Example: Channel 1 of lite blue will have two PIMs. At time of installation one PIM will be interfacing with 5 WAPMs and the other will be interfacing with 6.

  • Page 130: Configuring Wa Series Locks

    A transaction may need to be produced in order for these settings to be sent to the WRI. 10 Make a note of the address as this will be used by the lite blue user interface to configure the lock.
  • Page 131 A transaction may need to be produced in order for these settings to be sent to the lock. Make a note of the address as this will be used by the lite blue user interface to configure the lock. 10 Configuration of the lock is complete. To set up another WA series lock, follow steps 1 through 9 above.
  • Page 132 Chapter 9 Schlage Wireless Readers Disconnecting WA Series Locks from the link mode To disconnect lock from the link mode, close the CDT application. VLBIM06/15/15 v4.1.0...

  • Page 133: Vevms-Vbb Video Server Integration

    Integrating a access control panel with the will provide the ability to view and search video based on lite blue transactions. After configuring lite blue to communicate with an VEVMS Video Control MultiVideo Remote DVR/NVR, alarms can be shown in based on transactions.

  • Page 134: Cameras

    Chapter 10 VEVMS-VBB Video Server Integration Cameras The following cameras are compatible with the VEVMS-VBB Video Server: VLBIM06/15/15 v4.1.0...

  • Page 135: Configuration

    134 lite blue Installation Manual Configuration lite blue VEVMS DVR/NVR To configure to work with an , follow these steps: VEVMS DVR/NVR System Tools --> Advanced Settings VBB Service On the , go to . Click the Enable VBB Service...
  • Page 136 The lite blue Authentication window will open. vanderbilt Enter into the User Name field. vanderbilt Enter into the Password field. vanderbilt Enter into the Password Confirm field. Click the button. The window will close; lite blue Authentication is complete. VLBIM06/15/15 v4.1.0...
  • Page 137 Video Control is desired). Cameras configured to record based on lite blue VMD Continuously transactions can also be configured to record by (in addition to lite blue transactions). VMD Event, Store by Contact Input, and Store Continuously cannot be used in addition to lite blue transactions.
  • Page 138 This also enables the Right Click feature in Video Control, which will display a list of the last few lite blue transactions. The Shift + Right Click number of transactions displayed using is defined in Step 2.
  • Page 139 Check off " " and enter the IP Save Changes address, user name (vanderbilt) and password (vanderbilt). Click to establish a connection. If successful, the camera list will appear on the right hand side. Time Zone...
  • Page 140 Synchronize lite blue's date and time with the Video After saving the updated Time Zone, click " Surveillance System now. " The time will continue to be synchronized regularly between lite blue and the VEVMS DVR/NVR. lite blue Door Setup -->...

  • Page 141: Viewing Lite Blue Transaction Alarms

    140 lite blue Installation Manual Viewing lite blue Transaction Alarms Pop Up Display lite blue Video Control is configured, incoming transactions from will create alarms in For details on Pop Up Display see the VEVMS Manual. View Video from the Current Alarm -...
  • Page 142 - Once the Alarm Silence / Acknowledge button is clicked, holding down Shift right clicking on a lite blue linked camera will display a drop down list of recent alarms. The number Video Server Settings --> Store Settings Number of of alarms shown in this list is defined in in the "...
  • Page 143 142 lite blue Installation Manual VVTRPlay5 VVTRPlay5 - When an alarm is selected using either of the previous two methods, the window will appear. The video associated with the transaction will play automatically. VVTRPlay5 includes standard controls to Meta Data Pause, Fast Forward, and Rewind the video transaction.

  • Page 144: Searching For Lite Blue Transaction Alarms

    Chapter 10 VEVMS-VBB Video Server Integration Searching for lite blue Transaction Alarms lite blue Video can also be searched through based on transactions. This is done through the standard Find Playback utility in the application by following these steps. Select the desired Date / Time range, Facility, VEVMS DVR/NVR and Camera(s), then click the Video button.
  • Page 145 144 lite blue Installation Manual Event Type All Event Types Specify the or keep the default of and click OK. Playback. View the associated video in It will appear like any other video event type (VMD, Contact Input, Meta Data Event etc.), except extra fields will appear listing any...

  • Page 146: Troubleshooting

    Overview This chapter details how to troubleshoot and fix various issues with lite blue. If your system is not functioning properly, check this chapter for possible fixes. If you do not find your problem here, or if the recommended fix does not solve the problem, contact technical support for assistance.

  • Page 147: Upgrading Software

    File Not Authorized Warning While Upgrading Check the date that lite blue is set to. This error occurs if lite blue's date is out of synch with the current date. If the date will not reset the battery needs to be changed. See the Battery Replacement section for details.

  • Page 148: Date And Time

    Date and Time Incorrect Date/Time If the system is working properly, but the date and time are not correct, then the Lithium battery on the lite blue board needs to be replaced. See the Battery Replacement section for details. Slowly Losing/Gaining Time...

  • Page 149: Index

    Configuring WA Series Locks • 129 Connecting to HHD/Coupling/Linking • 108 Hardware Not UL Evaluated • 9 Connecting to lite blue • 47, 56, 63, 81, 88, 93 Highlights • 19, 43, 53, 59, 68 Connecting to Read Head • 49, 56, 64, 82 Hours of Technical Support •...
  • Page 150 Linking/Addressing • 105 SBB-RI Enclosure • 59 lite blue • 18 SBB-RI Pin Functions • 61 lite blue Date and Time Setup • 35 SBB-RI Pin Layout • 61 lite blue IP Configuration • 27 Schlage AD-400 Components • 96 lite blue LED Indicators •...
  • Page 151 Wireless Reader Interface (WRI – Indoor or Outdoor) • 121 Wireless reader modules configuration • 123 Wiring between lite blue and PIM Module • 123 Wiring between lite blue and PIM400 • 100 Wiring instructions • 122 Wiring Instructions • 100...
  • Page 152 ©2015 Vanderbilt Industries 04002 6/15...

Table of Contents
