Table 22. PowerMIB Objects (Continued)
MIB Object
xupsTopoMachineCode
xupsTopoUnitNumber
xupsTopoPowerStrategy

Eaton Pulsar MIB

This section contains an overview of MIB definitions for the following MIB files:
Eaton Pulsar MIB (MGE MIB)
l
Eaton Pulsar MIB (MGE MIB) for an Environmental Monitoring Probe (EMP)
l
The Network Card-MS implements the reduced Eaton Pulsar MIB (MGE MIB); only the objects listed in
Table 23 and Table 24are managed. The entire MIB description is available at www.eaton.com/powerquality.
Table 24 lists objects that are managed if there is an optional EMP installed. The Eaton Pulsar MIB trap access
path is 1.3.6.1.4.1.705.1.
Table 23. Eaton Pulsar MIB (MGE MIB) Objects
MIB Object
upsmgIdentFamilyName
upsmgIdentModelName
upsmgIdentFirmwareVersion
upsmgIdentSerialNumber
upsmgConfigLowBatteryTime
upsmgConfigLowBatteryLevel
upsmgConfigAutoRestart
upsmgConfigVARating
upsmgBatteryRemainingTime
upsmgBatteryLevel
upsmgBatteryVoltage
upsmgBatteryCurrent
upsmgBatteryFaultBattery
upsmgBatteryReplacement
upsmgBatteryLowBattery
upsmgBatteryChargerFault
upsmgBatteryLowCondition
upsmgInputPhaseNum
mginputVoltage_1
mginputVoltage_2
mginputVoltage_3
mginputFrequency_1
mginputFrequency_2
mginputFrequency_3
mginputMinimumVoltage
mginputMaximumVoltage
SNMP Format
Integer
Integer
Integer
SNMP Format
String
String
String
String
seconds
%
1 (yes), 2 (no)
VA
seconds
%
deciVolts
deciAmps
1 (yes), 2 (no)
1 (yes), 2 (no)
1 (yes), 2 (no)
1 (yes), 2 (no)
1 (yes), 2 (no)
—
DeciVolts
DeciVolts
DeciVolts
DeciHz
DeciHz
DeciHz
—
—
Eaton Network Card-MS User's Guide P-164000100—Rev 1 www.eaton.com/powerquality
Add.path
{13.2.0}
{13.3.0}
{13.4.0}
Add.path
{1,1,0}
{1,2,0}
{1,4,0}
{1,7,0}
{4,7,0}
{4,8,0}
{4,9,0}
{4,12,0}
{5,1,0}
{5,2,0}
{5,5,0}
{5,6,0}
{5,9,0}
{5,11,0}
{5,14,0}
{5,15,0}
{5,16,0}
{6,1,0}
{6,2,1,2,1,0}
{6,2,1,2,2,0}
{6,2,1,2,3,0}
{6,2,1,3,1,0}
{6,2,1,3,2,0}
{6,2,1,3,3,0}
{6,2,1,4,0}
{6,2,1,5,0}
