6. Enter admin. The main menu displays (see Figure 8).
-------------------------------------------------------------
Eaton Network Card-MS
-------------------------------------------------------------
1 : Reset
2 : Network configuration
3 : Set Login Password to Default
4 : Return to Default Configuration
0 : Exit
-------------------------------------------------------------
Figure 8. Network Card-MS Main Menu

Configuring the Network With a DHCP Server

The card automatically collects the IP parameters from the server by default.
NOTE When the card is not connected to the network, it continuously attempts to
connect. When the connection is established, the LEDs indicate the status (Table 1
on page 4).
To view the parameters:
1. From the main menu, type 2 and press Enter. The Network Settings menu displays (see Figure 9).
-------------------------------------------------------------
Network settings
-------------------------------------------------------------
1 : Read Network settings
2 : Modify Network settings
3 : Set Ethernet speed
0 : Exit
-------------------------------------------------------------
Figure 9. Network Settings Menu
