Eaton Powerware Series Quick Start Instructions
Web/snmp card
Hide thumbs
Also See for Powerware Series:
- User manual (120 pages) ,
- Mechanical installation manual (28 pages) ,
- Instructions manual (16 pages)
Related Manuals for Eaton Powerware Series
Summary of Contents for Eaton Powerware Series
- Page 1 Powerware Series ® Eaton ConnectUPS Web /SNMP Card Quick Start Instructions X and BD Models...
- Page 2 International Business Machines, Inc. All other trademarks are property of their respective companies. ECopyright 2005–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton Corporation.
- Page 3 J Load Segment 2 is connected to J Load Segment 3 is connected to Examples of load segment equipment connections are “CPU MX1,” “Monitor MX1,” and “Router San Diego 1.” ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185 Rev B www.eaton.com/powerquality...
- Page 4 ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185Rev B www.eaton.com/powerquality...
-
Page 5: Install The Card
Web browser or Telnet (or similar) utility, refer to the ConnectUPS Web/SNMP Card User's Guide PDF on the Software Suite CD. Figure 4. Install the Ethernet Cable ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185 Rev B www.eaton.com/powerquality... -
Page 6: Connect The Card
The UPS should be turned on. Type your password (the default is admin) and press Enter. The Main Menu screen appears. Figure 8. Enter Configuration Password ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185Rev B www.eaton.com/powerquality... -
Page 7: Configure The Card
The menus are identical to those seen during serial configuration and are password-protected for Superuser access only. Figure 12. ConnectUPS Card Summary Page ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185 Rev B www.eaton.com/powerquality... -
Page 8: Install Shutdown Software
Select the correct UPS load segment that your computer's power cord is plugged into and select (see Figure 16). Figure 16. Select UPS Load Segment ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185Rev B www.eaton.com/powerquality... - Page 9 UPS using this specific card. NetWatch installation and configuration is now complete. Figure 18. Verify Configuration Settings Figure 19. Verify Configuration Settings Figure 20. Clear Communication Message ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185 Rev B www.eaton.com/powerquality...
- Page 10 ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185Rev B www.eaton.com/powerquality...
- Page 12 ® Eaton ConnectUPSt Web/SNMP Card (X and BD Models) Quick Start Instructions 164950185 www.eaton.com/powerq *164950185B* 164950185 B...
