2. Type 1 and press Enter. The card displays the settings supplied by the server (see Figure 10).
-------------------------------------------------------------
Network configuration
-------------------------------------------------------------
MAC address : xx:xx:xx:FD:xC:xx
Mode : Static IP
IP address : xxx.xx.xxx.87
Link Local IPv6 address : FExx::xxx:xxFF:FEFD:xxxx/xx
Global IPv6 address :
2001:xxx:xxx:xxxA:xxx:xFF:FSFD:xxxx/xx
Global IPv6 address :
1789:xxx:xxx:xxxA:xxx:xxFF:FSFD:xxxx/xx
Subnet mask : 255.255.xxx.0
Gateway : xxx.xx.xxx.1
-------------------------------------------------------------
Figure 10. Network Configuration Menu
3. Record the IP address. The IPv6 parameters are read only.
4. To exit, type 0 and press Enter; then type 0 and press Enter again. The card is now operational.
NOTE As long as the card is not connected to the network, it continuously attempts to
make connection. Once the connection has been established, the operational mode
presended in the table becomes effective.

Configuring the Network Without a DHCP Server

To set the network configuration manually:
1. From the main menu, type 2 and press Enter. Type 2 and press Enter again to modify the network settings.
The Network Settings menu displays (see Figure 11).
-------------------------------------------------------------
Network settings
-------------------------------------------------------------
1 : Read Network settings
2 : Modify Network settings
3 : Set Ethernet speed
0 : Exit
-------------------------------------------------------------
For each of the following questions, you can press <Return> to select
the value shown in braces, or you can enter a new value.
Should this target obtain IP settings from the network?[N] N
Static IP address [xxx.xx.xxx.xx]? xxx.xx.xxx.87
Static IP address is xxx.xx.xxx.87
Subnet Mask IP address [255.255.xxx.0]? 255.255.xxx.0
Subnet Mask IP address is 255.255.xxx.0
Gateway address IP address [xxx.xx.xxx.1]? xxx.xx.xxx.1
Gateway address IP address is xxx.xx.xxx.1
Wait while your new configuration is saved...
Reset the card to enable the new configuration.
Figure 11. Modifying the Network Settings
