UPS Properties

Essential information about the UPS status is available on the UPS Properties page (see Figure 16), which
refreshes automatically every ten seconds.
The UPS Properties page shows an image and generic name of the UPS. You can customize the default location
Computer Room to name the location of your system (see "System Settings" on page 39).
An animated diagram displays for online UPSs showing an overview of the current UPS operating mode.
Figure 16. UPS Properties Page
UPS Status
UPS Status List
Eaton Network Card-MS User's Guide P-164000100—Rev 1 www.eaton.com/powerquality
Configuring the Card
Current UPS Operating
Mode Diagram
