2.
Plug the other end of the serial cable into the serial COM port on the computer.
3.
Connect an active Ethernet cable (not supplied) to the Ethernet port on the Network Card-MS (see
Figure 5).
Wait approximately two minutes until the UPS Data LED flashes regularly, indicating normal operation.
Ethernet Port
Settings/Sensor Port
Figure 5. Connecting the Card
Ethernet
Eaton Network Card-MS User's Guide P-164000100—Rev 1 www.eaton.com/powerquality
Getting Started
8
