Chapter 2

Getting Started

This chapter explains:

Unpacking the card

l
Installing and connecting the card
l
Installing the optional Environmental Monitoring Probe (EMP)
l
Configuring and the card
l
Unpacking the Card
Verify the package contents:
Network Card-MS
l
Serial cable
l
Installation instructions
l

Installation Checklist

1. Verify that all of the following items are available:
Network Card-MS package contents
l
Phillips
l
Ethernet cable
l
Available serial port (RS-232)
l
HyperTerminal
l
Web browser (Microsoft Internet Explorer
l
2. Provide the local network administrator with the card's MAC address:
MAC Address Port: _________________________
l
The MAC address is located on the label on the front of the card (see Figure 1).
l
Figure 1. MAC Address Location
®
screwdriver
®
(ships with Microsoft
MAC Address
Eaton Network Card-MS User's Guide P-164000100—Rev 1 www.eaton.com/powerquality
® ®
Windows ) or equivalent terminal emulation application
® ® ®
or Mozilla Firefox recommended)
3
