To patch scrollers
Example: Patch scrollers for channel fixtures 4 through 8 to DMX addresses 104 through 108.
1
Select channels 4 through 8.
2
Press
.
DIM
3
Tap
SCROLLER
4
Enter the first DMX address, in this example the first DMX address is 104.
5
Press
.
ENTER
Or
Tap
.
SET
The scroller patch is stored.
To patch more than 1 DMX address to a channel (soft patching)
Example: Patch Port 2, DMX addresses 12 - 24 to channel 1.
1
Select channel 1.
2
Press
.
DIM
The touch screen is in
3
Select the DMX addresses on the keypad:
4
Press
or
ENTER
5
Press
to exit the DMX port display.
RESET
To clear patching
Example: Clear the patch assignment for channel 5 which is patched to port 1, DMX offset 5.
1
Press
.
DIM
The touch screen is in
2
Select dimmer 5.
3
Press
.
DELETE
Confirmation is requested.
4
Press
or
DELETE
The DMX address is cleared. Now a new DMX offset can be set for channel 5.
5
Press
to exit the DMX port display.
RESET
OR
1
Press
.
DIM
2
Select dimmer 5.
3
Tap
.
CLEAR
You are prompted to confirm the delete command.
4
Press
or
DELETE
The DMX address is cleared. Now a new DMX offset can be set for channel 5.
.
mode.
DMX Address
.
STORE
mode.
DMX Address
or tap
.
ENTER
OK
or tap
.
ENTER
OK
.
2/12
2/24
DLITE
Patching
33
