Compulite Dlite User Manual page 183

Feature Sub Menus Description
ETHERNET Enable VC
Enable
Art-Net
Network
Settings
CONNECT TO
PC
SMPTE Enable
Start Clock
Stop Clock
Restart
Clock
Teach
SMPTE
MIDI Enable MIDI
Load
Defaults
SOUND TO Enable
LIGHT
SLAVE none
MASTER none
For more information on SMPTE, MIDI, and Sound-to-Light, see
For more information on master/slave configuration, see
page 177.
Enable / disable DMX transmission over Ethernet.
ATTENTION! If the Ethernet cable is not connected
make sure that VC transmission is disabled.
Enable / disable Art-Net transmission over Ethernet.
Use the wheels to:
• Set the console's IP address.
• Set the console's Subnet mask.
• Set the VC.
Note: Use (dot key) to jump from byte to byte.
See "Connecting to a PC" on page 169.
ATTENTION! If the modem cable is not connected
make sure that Connect to PC is disabled.
Enable SMPTE communication.
Restart the SMPTE clock where it stopped.
Stop SMPTE clock.
Restart clock from 0:0:0:0.
Teach SMPTE for automatic playback.
Enabled for sound to light operation.
Enabled - the console is working as a backup console, tracking
the main (or master) console. When enabled the button has a
dark field.
Enabled - the console is working as a master console with a
second console working as a backup console. When enabled
the button has a dark field.
"Master/Slave Tracking Back Up"
System Setup and Operations
"Automated Playback" page
DLITE
171.
167
