The fields are:
Fields
In
Out
Focus
Color
beam
Navigate the fields in the time screen by:
Pressing
Tapping

Setting fade times for lighting objects

Unique fade in and delay fade times can be set for scenes, cues, chases, chase steps, and parameter
banks. Parameter banks may have different fade times than the overall scene, cue, or chase step. For
instance, set a unique fade time for the beam bank, so gobos jump in while all other parameters are
fading in.
Use the wheels or the keypad to set fade times.
Wheel 1 - Minutes
Wheel 2 - Seconds
Wheel 3 - Tenths (1/10) of seconds
When using the keypad, enter the fade time in seconds. Example: To set a fade time of 1
minute and 30 seconds, enter 90 (seconds) on the keypad.
To set overall fade times
Example: Set lighting object 1 to fade in time over 1 minute and 30 seconds
1 To set fade times for scenes: Press
To set fade times for cues: Press
To set fade times for chase steps: Press
press
To set fade times for chases: Press
2 Press
The fade time fields are displayed in time mode.
3 Turn wheel 1 until arriving at 1 (minute) and the turn wheel 2 until arriving at 30 (seconds).
Or
Instead of using the wheels, enter 90 (seconds) on the keypad.
4 Press
Fade times
Set fade in and delay in times for the entire scene, cue, chase, or chase step.
Set fade out and delay out times for the entire scene, cue, chase, or chase step.
Set fade and delay times for the parameters in the F(ocus) bank.
Set fade and delay times for the parameters in the C(olor) bank.
Set fade and delay times for the parameters in the B(eam) bank.
to navigate the fields
or to enter the time values in the appropriate column.
FADE DELAY
1.
.
TIME
or or tap
ENTER STORE
and press .
SCENE 1
and select the QList. Then press
QLIST
and select the chase. Then press
CHASE
and select the chase.
CHASE
.
OK
DLITE
Programming Lighting Objects
and press
CUE
and
STEP
.
1
93
