Dlite default times

You can set default fade times for a number of operations.
For details, see

Console output

Output can originate from the editor, faders, playbacks, and crossfader. Output source is color
coded on the external monitor.

Output sources

Source
Editor
Faders
Playbacks
Crossfader Cues

Output Level Conventions

Output priority is determined by the parameter definition as defined in the Device Builder.
(see "Device Builder" page
for moving lights dimmers may also be LTP. Most other parameters are output as LTP.

HTP (Highest Takes Precedence)

Intensity output works according to HTP (Highest Takes Precedence). When the dimmer is
controlled by more than one source, the highest intensity level between the sources is output.
Example: Channel 6 is in scene 1 @50%, in scene 5 @ FL, and in scene 9 @ 25%. Scene 1 is
loaded to playback 1, scene 5 to playback 5, and scene 9 to playback 9 and all the playback sliders
are full, therefore channel 6 is output according to its dimmer setting in scene 5 (FL). Pulling down
playback 5 fades channel 6 to 50% as output from scene 1 on playback 1.

LTP (Latest Takes Precedence)

The last playback device that executed a playback command grabs output priority. Go commands, a
slider moved off its 0% limit, and pressing the flash key are playback commands.
Most parameters, except dimmer, usually work on the principle of LTP (Latest Takes Precedence).
LTP parameters may fade or jump between values.
"Defaults" page 165.
What is output
Levels for the active parameters
Channels in and
Wide 2 Preset
Scenes, chase steps, or cues
167.) Dimmers, normally channels, are usually output as HTP, although
Color code on the external screen
• Red - active on the wheels
• White - present in the editor
modes Dark Gray
• Green (scenes)
• Red (chases)
• Light blue (cues)
Light blue
