External monitor display modes

Figure 6: External monitor display dialog box
You can configure the external monitor display to show:
0. All Fixtures
1. Channels
2. Spots
3. Extra
Jump display
Display Parameter Fade
Time
Select color scheme

Navigating and selecting displays

You can navigate this dialog box and select the display:
Use the
on the console keypad to select the display.
Enter the display number on the console keypad and click
Using an external mouse, clicking to select the display. Then click
Using the trackball in mouse mode. Press the
to close the dialog box.
OK
6
4. Spots, channels
5. Spots, U Keys
6. Channels, Ukeys
7. Spots, Channels, U Keys
The display jumps to the selected channel, extra, or spot parameter.
Check to enable.
An extra row, showing parameter fade times, is added to the live fixture
displays. Check to enable.
Choose standard gray or basic black.
and keys to navigate. Press the space bar on the external keyboard or
PREV NEXT
8. U Keys, QList
9. Spots, Channels, QList
10 Spots, QList, U Keys
SHIFT
to close the dialog box.
OK
OK
or lock keys to select the display. Then click
X Y
+ selects view 10
to close the dialog box.
