Compulite Dlite User Manual page 142

Compulite
Chapter 9
Effect buttons on the touch screen
Button
+BASE
RELEASE
HOME
There are additional effect controls accessed by pressing the effect screen's
UP
CENTER
DOWN
NORMAL
CENTER
RANDOM
SYNC
INVERT SIZE
When the
Wheels in effect mode
Wheel
Time
Size
Base
Offset
# (number) of Fixt(ures)
#
of Loops
128
What it does
Include base when storing. See
page
Release the fixture from effect. Parameters return to the base value.
Release the fixture from effect. Parameters return to their home
values.
Switch effect direction. See
Control the direction and scope of an effect. See
page 131.
These settings control the progression of the effect. See
fixture progression in effects" page
Synchronize effects that are running simultaneously.
Inverting the size reverses the direction of the effect.
screen is open, the parameter wheels control effect attributes:
Effect
What it does
Sets the number of seconds it takes to complete one effect cycle.
Determines direction and scope of the effect in relation to the base
value.
Change the base value for parameters participating in the effect.
Controls the point at which a parameter begins its action within the
time cycle.
Fixture grouping with offset determines how the offset is spread
among the devices.
Example: An intensity jump effect is running on spots 1 through 10.
All 10 spots turn on and off at the same time. Set the fixture grouping
to 2 and tap
are off and vice verse.
Set the number of times the effect repeats.
138.
"Setting the effect direction" page
. Now the odd spots are on when the even spots
WAVE
"Include base levels in stored effects"
MORE...
"Direction and scope"
"Determining
141.
button.
141.
