Chapter 9

Customize

You can customize the effect's basic movement pattern. Different effect types can be assigned to
each parameter. Combining effect types is a quick way to create complex effects.
Movement type
None
Jump
Fade
Pulse
Other basic types, accessed by tapping
Cos(ine)
Trpz (trapezoid)
Tri(angle)
Hold
SprlX (spiral on the pan axis)
SprlY(spiral on the tile axis)
Saw
Note:
To set a movement type
Example: Set the jump movement type for the dimmer parameter for moving lights 1 through
6.
1
Select moving lights 1 through 6.
2 Press the dimmer wheel to select the dimmer parameter.
Or
Set a base dimmer level.
3 Press
4
Tap
The effect begins working immediately.

Base

Base is the parameter level that defines the effect's starting point. Base level are parameter and spot
specific. Set the base level prior to accessing the
the wheel labelled with the last parameter selected can be used to change the base level.
130
What it does
No effect is running.
The parameter level jumps from the base to FL and jumps back to the
base.
The parameter level fades from the base to FL and fades back to the base.
The parameter level fades from the base to FL, pauses, fades back to the
base, and pauses again before repeating.
When no parameter is selected, the effect screen opens to the
you have selected a parameter, the screen opens to
.
EFFECT
.
JUMP
, are:
MORE...
screen. When the effect is running,
Effect Editor
effects. If
Generic
effects.
Customize
