Chapter 9
7 Tap
All

Fixture grouping

Fixture grouping with an offset determines how the offset is spread among the devices and which
fixtures are synchronized.
Example: An intensity step effect is running on spots 1 through 10. All 10 spots turn on and off at
the same time. Set the fixture grouping to 2 and set an offset. Now the odd spots are on when the
even spots are off and vice versa.
To set the fixture grouping
1
Select moving lights 1 through 6.
2 Set dimmer levels.
3 Press
4 Tap
The effect begins running.
5
Tap
6 Tap
7 Tap
8 Turn wheel 2 (

Basic effect programming

All effects parameters can be fine-tuned in order to achieve maximum flexibility.
To program an effect for selected parameter
1 Select fixtures.
2 Select the parameter by pressing on its wheel.
3
Optional, set a parameter level that will be used as the base.
4
Press
The
5 Chose a movement type by tapping
The effect begins running.
6
Optional - adjust base, size, offset, rate, swing.
7 Store effect as a scene, chase, step, cue, or effect library.
136
again cancel the offset and return to the default functioning.
WAVE/ONE-ON
appears next to the fixture number on the touch screen.
.
EFFECT
.
JUMP
.
WAVE/ONE ON
.
PAGE WHEELS
# OF FIXT.
) until the required fixture grouping is displayed.
# of Fixt.
.
EFFECT
screen is displayed.
Effect
, , or
JUMP FADE PULSE
.
