Fixture selection order

The order in which fixtures are selected determines the order in which the effect is executed.
Example: If the spot selection was 1
If the spot selection was 12
also true for non-sequential spot selections.

Generic effects

Dlite is supplied with generic effects. All generic effects attributes can be modified. Note that some
of the generic effects are pre-programmed to run on specific parameters, such as Cyan Mag that
runs on the cyan and magenta parameters. You can also build your effects from scratch using the
movement types and attributes that are available in the
Generic effects range from effect 49 through effect 68.
.
Dlite is supplied with 20 pre-programmed effects. Pre-programmed effects start at number 49.
49. Circle
50. Scan
51. Fly Out
52. Scissor
53. Spiral
To use generic effects
1 Press
2 Press
3 Choose an effect by tapping it on the touch screen.
The effect starts running immediately.

Movement attributes

Effects' movement attributes are:
Generic or Customize
Base
Up, Down, Center
Size
1, spot 12 is the first spot to respond, spot 11 is the next, etc. This is
54. Triangle
55. Square
56. Cyan Mag(enta)
57. Mag(enta)
Yel(low)
58. Cyan Yel(low)
and select fixtures.
SPOT
.
EFFECT
12, spot 1 is the first spot to respond, spot 2 is the next, etc.
screen.
Effect
59. Cyan Mag(enta)
Yel(low)
60. Dim On Of
61. Dim Fade
62. 3 Circ(le)
Shadow
63. Iris Fade
DLITE
Effects
64. Iris Pulse
65. Foc(us) Fade
66. Zoom Fade
67. Frost Fade
68. Frost Pulse
129
