SA (Spectrum Analyzer) Mode
SA Mode Settings
How to make Independent Source Settings
— Press Measure 1
— Then
—
—
—
—
—
By default, the source output will turn off momentarily at the end of each
IQA and SA sweep and also every 300 seconds during the InstAlign
process.
To cause the source to stay ON at the end of each sweep, turn battery saver
OFF. (Learn more in
162
Source
Source Enable ON OFF
— ON Turns ON the internal source.
— OFF Turns OFF the internal source.
Source Mode Choose from the following:
— Tracking The internal source frequency can track the SA receiver.
Center frequency
— CW The source is set to a CW frequency independent from the SA
settings. Srcw is annotated on the screen.
— Coupled CW The source is set to a CW frequency, but that frequency
"tracks" the SA receiver Center Frequency settings. Therefore, the
signal always appears at center of the display.
the screen.
Normalize ON OFF With Source Enable ON and Source Mode = Tracking,
Normalize ON stores the current measurement trace into Trace 4 in View
state as a reference trace. All subsequent trace measurements subtract
this Trace 4 reference trace, and therefore become relative to it.
annotated on the screen. Normalize is automatically turned OFF when the
frequency range or Resolution is changed. Learn more about Trace Display
States in "Trace Display States (SA Mode)" on page
Source Power Sets the source power level. Choose from:
— Leveled Enter a value from -45 dBm to 0 dBm using the numeric
keypad, arrows, or the rotary knob
reasonably flat across the frequency span.
— MAX The power level is set to the maximum achievable power level at
each frequency. This results in the power level NOT being flat across
the frequency span.
Source CW Freq Sets the CW frequency that is used when Source Mode is
set to CW.
"How to Access Individual Alignments" on page
1. N995xA/6xA cannot have the Leveled value set lower than –35 dBm.
Src is annotated on the screen
Keysight N9927-90001 User's Guide
Srcp is annotated on
SrcN
175.
1
. The source power is
181.)
is
